Dayton Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity - IEC Thermal Overload Relays
DaytonIEC Thermal Overload Relays

Dayton Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity

The DAYTON Overload Relay (MPN 6ECC6) is a 3-pole IEC thermal overload relay with integrated bimetallic elements, eliminating the need for separate thermal units. It features 1NO/1NC auxiliary contacts and phase loss…

SKU 3G-OTH-40796

Brand
Dayton
Item
Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity
Category
IEC Thermal Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
6ECC6
Type
1NO/1NC, Phase Loss Sensitivity, 17 A – 25 A
Poles
3
Compatible Contactors
Dayton (25 to 32 Amps Models)
Auxiliary Contact Form
1NO/1NC
Phase Loss Sensitivity
Yes
Thermal Units Required
None (Relay Includes Integrated Bimetallic Elements)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Overload Relay (MPN 6ECC6) is a 3-pole IEC thermal overload relay with integrated bimetallic elements, eliminating the need for separate thermal units. It features 1NO/1NC auxiliary contacts and phase loss sensitivity, and is compatible with Dayton contactors rated 25 to 32 Amps. The relay provides thermal protection for motors within a 17 A to 25 A adjustment range.

Frequently Asked Questions

What is the DAYTON Overload Relay 6ECC6 used for?

The DAYTON Overload Relay 6ECC6 provides thermal protection for three-phase motors by monitoring current and tripping on overload or phase loss. It is used in industrial motor control panels, conveyors, pumps, and HVAC equipment to prevent motor damage from excessive current or unbalanced phases.

What are the specifications of the DAYTON Overload Relay 6ECC6?

The DAYTON Overload Relay 6ECC6 is a 3-pole IEC thermal overload relay with integrated bimetallic elements, so no separate thermal units are needed. It has a current adjustment range of 17 A to 25 A, 1NO/1NC auxiliary contacts, and phase loss sensitivity. It is compatible with Dayton contactors rated 25 to 32 Amps.

Where to buy the DAYTON Overload Relay 6ECC6 worldwide?

3G Electric supplies the DAYTON Overload Relay 6ECC6 to customers worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time; we source and deliver this relay to any international destination.

How to select the correct DAYTON Overload Relay for a motor?

Select a DAYTON overload relay by matching its current adjustment range to the motor's full-load amperage. For the 6ECC6, set the dial between 17 A and 25 A. Ensure the relay's pole count and auxiliary contacts (1NO/1NC) suit your control circuit, and verify compatibility with your Dayton contactor model rated 25 to 32 Amps.
