Dayton Definite Purpose Magnetic Contactor: 3 Poles, 208-240V AC, 75 A - Non-Reversing Definite Purpose Contactors
DaytonNon-Reversing Definite Purpose Contactors

Dayton Definite Purpose Magnetic Contactor: 3 Poles, 208-240V AC, 75 A

The DAYTON Definite Purpose Magnetic Contactor (MPN 783XY1) is a non-reversing, three-pole contactor with a 3NO main pole contact form, designed for HVACR definite purpose applications. It features a 208/240V AC coil…

SKU 3G-OTH-43859

Brand
Dayton
Item
Definite Purpose Magnetic Contactor: 3 Poles, 208-240V AC, 75 A
Category
Non-Reversing Definite Purpose Contactors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
783XY1
Type
75 A, Non-Reversing
AC
208-240V
Phase
Three
Coil Voltage
208/240V AC
Mounting Style
Through Panel
Contactor Style
HVACR Definite Purpose Contactor
Main Pole Contact Form
3NO
Maximum Voltage Rating
600V AC
Terminal Connection Type
Box Lugs
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Definite Purpose Magnetic Contactor (MPN 783XY1) is a non-reversing, three-pole contactor with a 3NO main pole contact form, designed for HVACR definite purpose applications. It features a 208/240V AC coil voltage, a maximum voltage rating of 600V AC, and box lug terminal connections, with a through-panel mounting style.

Frequently Asked Questions

What is the DAYTON Definite Purpose Magnetic Contactor 783XY1 used for?

The DAYTON 783XY1 is a non-reversing definite purpose contactor designed for HVACR applications such as controlling compressors, fans, and pumps in commercial heating, ventilation, air conditioning, and refrigeration systems.

What are the specifications of the DAYTON 783XY1 contactor?

The DAYTON 783XY1 is a three-pole, non-reversing definite purpose contactor with a 208/240V AC coil voltage, 75 A rating, 600V AC maximum voltage, 3NO main pole contact form, box lug terminals, and through-panel mounting. It is a DAYTON brand HVACR component.

Where to buy the DAYTON 783XY1 contactor worldwide?

3G Electric supplies the DAYTON 783XY1 definite purpose contactor worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the DAYTON 783XY1 definite purpose contactor?

Mount the DAYTON 783XY1 through the panel using the provided holes. Connect power and load wires to the box lug terminals, ensuring torque per manufacturer specs. Apply 208/240V AC to the coil. Always follow local electrical codes and de-energize before installation.
