Dayton Definite Purpose Magnetic Contactor: 3 Poles, 208-240V AC, 90 A - Non-Reversing Definite Purpose Contactors
DaytonNon-Reversing Definite Purpose Contactors

Dayton Definite Purpose Magnetic Contactor: 3 Poles, 208-240V AC, 90 A

The DAYTON Definite Purpose Magnetic Contactor (MPN 783XY3) is a non-reversing, three-pole contactor designed for HVACR applications. It features a 208/240V AC coil voltage, a maximum voltage rating of 600V AC, and a…

SKU 3G-OTH-44217

Brand
Dayton
Item
Definite Purpose Magnetic Contactor: 3 Poles, 208-240V AC, 90 A
Category
Non-Reversing Definite Purpose Contactors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
783XY3
Type
90 A, Non-Reversing
AC
208-240V
Phase
Three
Coil Voltage
208/240V AC
Mounting Style
Through Panel
Contactor Style
HVACR Definite Purpose Contactor
Main Pole Contact Form
3NO
Maximum Voltage Rating
600V AC
Terminal Connection Type
Box Lugs
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Definite Purpose Magnetic Contactor (MPN 783XY3) is a non-reversing, three-pole contactor designed for HVACR applications. It features a 208/240V AC coil voltage, a maximum voltage rating of 600V AC, and a 90 A rating, with a 3NO main pole contact form. This through-panel mounted unit uses box lug terminals for secure connections.

Frequently Asked Questions

What is the DAYTON Definite Purpose Magnetic Contactor 783XY3 used for?

The DAYTON 783XY3 definite purpose magnetic contactor is designed for HVACR applications such as controlling compressors, fans, and pumps. Its 90 A rating and 208/240V AC coil make it suitable for three-phase equipment requiring non-reversing switching up to 600V AC.

What are the specifications of the DAYTON 783XY3 contactor?

The DAYTON 783XY3 is a three-pole, non-reversing definite purpose contactor with a 208/240V AC coil voltage, 90 A rating, and maximum voltage rating of 600V AC. It features a 3NO main pole contact form, through-panel mounting, and box lug terminals for secure connections.

Where to buy the DAYTON 783XY3 contactor worldwide?

You can source the DAYTON 783XY3 contactor through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this HVACR definite purpose contactor.

How to install the DAYTON 783XY3 definite purpose contactor?

Mount the DAYTON 783XY3 through a panel using the provided holes, ensuring proper alignment. Connect power and load wires to the box lug terminals, torquing to manufacturer specifications. Verify coil voltage matches 208/240V AC supply. Always follow local electrical codes and disconnect power before installation.
