EATON Supplementary Protector: 5 A Amps, 96V DC, 15kA at 240/415V AC, Lug, FAZ - D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATOND-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 5 A Amps, 96V DC, 15kA at 240/415V AC, Lug, FAZ

The EATON FAZ-D5/3 is a D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 5 Amps. It carries an AC voltage rating of 277/480V AC, a DC voltage rating of 96V DC, and a maximum AIR rating of 15kA…

SKU 3G-OTH-20448

Brand
EATON
Item
Supplementary Protector: 5 A Amps, 96V DC, 15kA at 240/415V AC, Lug, FAZ
Category
D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-D5/3
Series
FAZ
Type
15kA at 240/415V AC, Lug, FAZ
AC
277/480V
DC
96V
Max. AIR Rating
15kA at 240/415V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-D5/3 is a D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 5 Amps. It carries an AC voltage rating of 277/480V AC, a DC voltage rating of 96V DC, and a maximum AIR rating of 15kA at 240/415V AC. This IEC supplementary protector features a lug terminal connection and is part of the EATON FAZ series.

Frequently Asked Questions

What is the EATON FAZ-D5/3 supplementary protector used for?

The EATON FAZ-D5/3 is a D-curve, 3-pole UL1077 supplementary protector rated at 5 Amps. It protects branch circuits and equipment against overloads and short circuits in industrial control panels, HVAC systems, and lighting applications where overcurrent protection is needed up to 277/480V AC or 96V DC.

What are the specifications of the EATON FAZ-D5/3?

The EATON FAZ-D5/3 is rated at 5 Amps with a D-curve trip characteristic. It has an AC voltage rating of 277/480V AC, a DC voltage rating of 96V DC, and a maximum AIR rating of 15kA at 240/415V AC. It features a lug terminal connection and is part of the EATON FAZ series.

Where to buy the EATON FAZ-D5/3 worldwide?

You can source the EATON FAZ-D5/3 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON FAZ series supplementary protectors to procurement teams globally.

How to select the correct EATON FAZ-D5/3 for an application?

Select the EATON FAZ-D5/3 by matching its 5 Amp rating, D-curve, and voltage ratings (277/480V AC or 96V DC) to your circuit's load and fault current. Ensure the 15kA interrupting capacity at 240/415V AC exceeds available fault current. Use a DIN rail mount and lug terminals for secure connection. Consult a licensed electrician for proper coordination.
