EATON Supplementary Protector: 40 A Amps, 96V DC, 10kA at 277/480V AC, Lug, FAZ - D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATOND-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 40 A Amps, 96V DC, 10kA at 277/480V AC, Lug, FAZ

The EATON FAZ-D40/3 is a 40 A, D-Curve, 3-pole UL1077 DIN rail-mount supplementary protector from the FAZ series. It features a lug terminal connection and is rated for 277/480V AC with a maximum interrupting rating…

SKU 3G-OTH-20959

Brand
EATON
Item
Supplementary Protector: 40 A Amps, 96V DC, 10kA at 277/480V AC, Lug, FAZ
Category
D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-D40/3
Series
FAZ
Type
10kA at 277/480V AC, Lug, FAZ
AC
277/480V
DC
96V
Max. AIR Rating
10kA at 277/480V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-D40/3 is a 40 A, D-Curve, 3-pole UL1077 DIN rail-mount supplementary protector from the FAZ series. It features a lug terminal connection and is rated for 277/480V AC with a maximum interrupting rating of 10kA at that voltage, as well as 96V DC.

Frequently Asked Questions

What is the EATON FAZ-D40/3 used for?

The EATON FAZ-D40/3 is a 40 A, D-Curve, 3-pole UL1077 supplementary protector used to protect branch circuits and equipment from overcurrent and short circuits in industrial control panels, HVAC systems, and machinery. It mounts on a standard DIN rail and is rated for 277/480V AC and 96V DC applications.

What are the specifications of the EATON FAZ-D40/3?

The EATON FAZ-D40/3 is a 40 A, D-Curve, 3-pole supplementary protector from the FAZ series. It has a lug terminal connection, AC voltage rating of 277/480V AC, DC voltage rating of 96V DC, and a maximum interrupting rating of 10kA at 277/480V AC. It is UL1077 listed for DIN rail mounting.

Where to buy the EATON FAZ-D40/3 worldwide?

You can source the EATON FAZ-D40/3 from 3G Electric, a global industrial equipment distributor established in 1990. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON FAZ series components.

How to install the EATON FAZ-D40/3 supplementary protector?

To install the EATON FAZ-D40/3, snap it onto a standard 35 mm DIN rail. Ensure the circuit is de-energized. Connect line and load wires to the lug terminals, tightening to the manufacturer's recommended torque. Verify the D-Curve trip characteristic matches your inrush load. Follow all applicable electrical codes.
