EATON Lighted Rocker Switch: 3 Positions, SPDT - General Purpose Rocker Switches
EATONGeneral Purpose Rocker Switches

EATON Lighted Rocker Switch: 3 Positions, SPDT

The EATON NGR Series Lighted Rocker Switch (MPN NGR15881BNAAN) is a general-purpose rocker switch with three positions (On/Off/On) and SPDT circuitry. It features an illuminated operator and is rated for AC contact…

SKU 3G-OTH-35086

Brand
EATON
Item
Lighted Rocker Switch: 3 Positions, SPDT
Category
General Purpose Rocker Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
NGR15881BNAAN
Series
NGR
Displayed Brand
EATON
AC Contact Rating
10 A @ 250 V
DC Contact Rating
15 A @ 28 V
Operator Illumination
Illuminated
Terminal Connection Type
0.25 in Quick Connect Tab
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NGR Series Lighted Rocker Switch (MPN NGR15881BNAAN) is a general-purpose rocker switch with three positions (On/Off/On) and SPDT circuitry. It features an illuminated operator and is rated for AC contact at 10 A @ 250 V and DC contact at 15 A @ 28 V. Termination is via 0.25 in Quick Connect Tabs.

Frequently Asked Questions

What is the EATON NGR15881BNAAN lighted rocker switch used for?

The EATON NGR15881BNAAN is a general-purpose lighted rocker switch used for on/off control in industrial panels, machinery, and equipment. Its three-position SPDT operation and illuminated actuator make it suitable for applications requiring visual status indication, such as motor controls and power distribution.

What are the specifications of the EATON NGR15881BNAAN rocker switch?

The EATON NGR Series switch (MPN NGR15881BNAAN) is a 3-position SPDT illuminated rocker switch. AC contact rating is 10 A @ 250 V; DC contact rating is 15 A @ 28 V. Termination uses 0.25 in Quick Connect Tabs. It is a general-purpose component from EATON.

Where to buy the EATON NGR15881BNAAN switch worldwide?

You can source the EATON NGR15881BNAAN lighted rocker switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the EATON NGR15881BNAAN rocker switch?

Install the EATON NGR15881BNAAN by connecting the 0.25 in Quick Connect Tabs to matching female terminals. Ensure power is off before wiring. The switch fits a standard panel cutout. Follow generic best practices for SPDT switches: common terminal to load, NC/NO terminals to power sources.
