EATON Lighted Rocker Switch: 2 Positions, DPST - General Purpose Rocker Switches
EATONGeneral Purpose Rocker Switches

EATON Lighted Rocker Switch: 2 Positions, DPST

The EATON NGR Series Lighted Rocker Switch (MPN NGR25061BNAAN) is a general-purpose rocker switch with a 2-position, DPST Off/On configuration. It features an illuminated operator and is rated for 15 A @ 125 V AC and…

SKU 3G-OTH-35157

Brand
EATON
Item
Lighted Rocker Switch: 2 Positions, DPST
Category
General Purpose Rocker Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
NGR25061BNAAN
Series
NGR
Displayed Brand
EATON
AC Contact Rating
15 A @ 125 V
DC Contact Rating
15 A @ 28 V
Operator Illumination
Illuminated
Terminal Connection Type
0.25 in Quick Connect Tab
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NGR Series Lighted Rocker Switch (MPN NGR25061BNAAN) is a general-purpose rocker switch with a 2-position, DPST Off/On configuration. It features an illuminated operator and is rated for 15 A @ 125 V AC and 15 A @ 28 V DC, with 0.25 in Quick Connect Tab terminals.

Frequently Asked Questions

What is the EATON NGR25061BNAAN lighted rocker switch used for?

The EATON NGR25061BNAAN is a general-purpose rocker switch used for on/off control in industrial equipment, panel boards, and machinery. Its DPST configuration and illuminated operator make it suitable for applications requiring visual status indication, such as power distribution and control panels.

What are the specifications of the EATON NGR25061BNAAN rocker switch?

The EATON NGR25061BNAAN is a 2-position, DPST Off/On lighted rocker switch from the NGR Series. It has an AC contact rating of 15 A @ 125 V and a DC contact rating of 15 A @ 28 V. Terminals are 0.25 in Quick Connect Tabs, and the operator is illuminated.

Where to buy the EATON NGR25061BNAAN rocker switch worldwide?

You can source the EATON NGR25061BNAAN rocker switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring reliable supply for your operations.

How to install the EATON NGR25061BNAAN lighted rocker switch?

To install the EATON NGR25061BNAAN, ensure power is off. Connect wires to the 0.25 in Quick Connect Tab terminals per the DPST Off/On wiring diagram. Mount the switch into a panel cutout and secure it. Verify illumination and switching function before restoring power.
