EATON Molded Case Circuit Breaker: 175 A Amps, 65kA at 480V AC, Fixed, ABC, Load Side Lug - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Molded Case Circuit Breaker: 175 A Amps, 65kA at 480V AC, Fixed, ABC, Load Side Lug

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PK6, MPN PDG23M0175TFFL) is a 175 A rated circuit breaker from the PD Series with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, a…

SKU 3G-OTH-24017

Brand
EATON
Item
Molded Case Circuit Breaker: 175 A Amps, 65kA at 480V AC, Fixed, ABC, Load Side Lug
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG23M0175TFFL
Series
PD Series
Type
65kA at 480V AC, Fixed, ABC, Load Side Lug, Std
Frame Size
2
Max. AIR Rating
65kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Load Side Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PK6, MPN PDG23M0175TFFL) is a 175 A rated circuit breaker from the PD Series with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, a fixed instantaneous trip, ABC phase connection, and load side lug terminal connection.

Frequently Asked Questions

What is the EATON PDG23M0175TFFL molded case circuit breaker used for?

The EATON Power Defense PDG23M0175TFFL is a 175 A molded case circuit breaker used for overcurrent protection in industrial power distribution systems. It is suitable for applications requiring a 65kA interrupting rating at 480V AC, such as motor control centers, panelboards, and switchboards.

What are the specifications of the EATON PDG23M0175TFFL circuit breaker?

The EATON PDG23M0175TFFL is a 175 A, 65kA at 480V AC molded case circuit breaker from the PD Series, Frame Size 2. It features a fixed instantaneous trip, ABC phase connection, and load side lug terminals. The part number is PDG23M0175TFFL.

Where to buy the EATON PDG23M0175TFFL circuit breaker worldwide?

3G Electric supplies the EATON PDG23M0175TFFL molded case circuit breaker worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this PD Series breaker.

How to select the right EATON Power Defense circuit breaker for my application?

To select the correct EATON Power Defense breaker like the PDG23M0175TFFL, verify your system voltage (480V AC), required interrupting rating (65kA), continuous current (175 A), and phase connection (ABC). Also confirm frame size and terminal type (load side lug) match your panelboard or switchboard.
