EATON Molded Case Circuit Breaker: 100 A Amps, 65kA at 480V AC, Fixed, ABC, Line/Load Lug - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Molded Case Circuit Breaker: 100 A Amps, 65kA at 480V AC, Fixed, ABC, Line/Load Lug

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PP6, MPN PDG23G0100TFFJ) is a 100 A rated device from the PD Series with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, a fixed…

SKU 3G-OTH-24078

Brand
EATON
Item
Molded Case Circuit Breaker: 100 A Amps, 65kA at 480V AC, Fixed, ABC, Line/Load Lug
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG23G0100TFFJ
Series
PD Series
Type
65kA at 480V AC, Fixed, ABC, Line/Load Lug, Std
Frame Size
2
Max. AIR Rating
65kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PP6, MPN PDG23G0100TFFJ) is a 100 A rated device from the PD Series with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, a fixed instantaneous trip, and ABC phase connection. The breaker is equipped with line/load lug terminal connections.

Frequently Asked Questions

What is the EATON PDG23G0100TFFJ molded case circuit breaker used for?

The EATON Power Defense PDG23G0100TFFJ is a 100 A molded case circuit breaker used for overcurrent protection in industrial and commercial power distribution systems. It safeguards branch circuits, feeders, and equipment from short circuits and overloads, particularly in panelboards and switchboards requiring a 65kA interrupting rating at 480V AC.

What are the specifications of the EATON PDG23G0100TFFJ circuit breaker?

The EATON PDG23G0100TFFJ is a 100 A, 65kA at 480V AC molded case circuit breaker from the PD Series, Frame Size 2. It has a fixed instantaneous trip, ABC phase connection, and line/load lug terminals. The MPN is PDG23G0100TFFJ, and it is part of the Power Defense family.

Where to buy the EATON PDG23G0100TFFJ circuit breaker worldwide?

You can source the EATON PDG23G0100TFFJ circuit breaker worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide reliable sourcing for this Eaton Power Defense breaker.

How to install the EATON PDG23G0100TFFJ molded case circuit breaker?

Install the EATON PDG23G0100TFFJ by mounting it securely in a suitable panelboard or switchboard. Connect line and load conductors to the line/load lug terminals, torquing to manufacturer specifications. Ensure the breaker is in the OFF position before wiring. Follow all local electrical codes and use proper personal protective equipment.
