EATON Molded Case Circuit Breaker: 30 A Amps, 65kA at 480V AC, Fixed, ABC, Load Side Lug - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Molded Case Circuit Breaker: 30 A Amps, 65kA at 480V AC, Fixed, ABC, Load Side Lug

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PM6, MPN PDG23M0030TFFL) is a 30 A, PD Series unit with a Frame Size of 2. It features a Max. AIR Rating of 65kA at 480V AC, a Fixed Instantaneous Trip, ABC…

SKU 3G-OTH-23601

Brand
EATON
Item
Molded Case Circuit Breaker: 30 A Amps, 65kA at 480V AC, Fixed, ABC, Load Side Lug
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG23M0030TFFL
Series
PD Series
Type
65kA at 480V AC, Fixed, ABC, Load Side Lug, Std
Frame Size
2
Max. AIR Rating
65kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Load Side Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PM6, MPN PDG23M0030TFFL) is a 30 A, PD Series unit with a Frame Size of 2. It features a Max. AIR Rating of 65kA at 480V AC, a Fixed Instantaneous Trip, ABC Phase Connection, and Load Side Lug terminal connection.

Frequently Asked Questions

What is the EATON Power Defense Molded Case Circuit Breaker used for?

The EATON Power Defense Molded Case Circuit Breaker is used for overcurrent protection in industrial and commercial electrical distribution systems. It safeguards circuits and equipment from short circuits and overloads, with a 30 A rating and 65kA interrupting capacity at 480V AC, suitable for high-fault applications.

What are the specifications of the EATON PDG23M0030TFFL circuit breaker?

The EATON PDG23M0030TFFL is a 30 A, PD Series molded case circuit breaker with a Frame Size of 2. It has a Max. AIR Rating of 65kA at 480V AC, Fixed Instantaneous Trip, ABC Phase Connection, and Load Side Lug terminal connection. It is part of the Power Defense line from EATON.

Where to buy the EATON PDG23M0030TFFL circuit breaker worldwide?

You can source the EATON PDG23M0030TFFL circuit breaker worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this EATON Power Defense unit.

How to select the right EATON molded case circuit breaker for your application?

To select the right EATON molded case circuit breaker, match the amp rating (e.g., 30 A) to your load, ensure the interrupting capacity (e.g., 65kA at 480V AC) exceeds available fault current, and verify phase connection (e.g., ABC) and terminal type (e.g., Load Side Lug). Consult a licensed electrician for code compliance.
