EATON Molded Case Circuit Breaker: 30 A Amps, 65kA at 480V AC, Instantaneous - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Molded Case Circuit Breaker: 30 A Amps, 65kA at 480V AC, Instantaneous

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PM9, MPN PDG23M0030MRAJ) is a 30 A, PD Series unit with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, instantaneous trip, ABC…

SKU 3G-OTH-23607

Brand
EATON
Item
Molded Case Circuit Breaker: 30 A Amps, 65kA at 480V AC, Instantaneous
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG23M0030MRAJ
Series
PD Series
Type
65kA at 480V AC, Instantaneous, ABC, Load Side Lug
Frame Size
2
Max. AIR Rating
65kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Instantaneous
Terminal Connection
Load Side Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PM9, MPN PDG23M0030MRAJ) is a 30 A, PD Series unit with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, instantaneous trip, ABC phase connection, and load side lug terminal connection.

Frequently Asked Questions

What is the EATON PDG23M0030MRAJ molded case circuit breaker used for?

The EATON Power Defense PDG23M0030MRAJ is a 30 A molded case circuit breaker used for overcurrent protection in industrial power distribution systems. It is suitable for applications requiring a 65kA interrupting rating at 480V AC, with instantaneous trip for short-circuit protection and ABC phase connection.

What are the specifications of the EATON PDG23M0030MRAJ circuit breaker?

The EATON PDG23M0030MRAJ is a 30 A, PD Series molded case circuit breaker with a Frame Size of 2. It has a maximum AIR rating of 65kA at 480V AC, instantaneous trip, ABC phase connection, and load side lug terminal connection. The manufacturer part number is PDG23M0030MRAJ.

Where to buy the EATON PDG23M0030MRAJ circuit breaker worldwide?

3G Electric supplies the EATON PDG23M0030MRAJ molded case circuit breaker worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this PD Series unit.

How to select the right EATON molded case circuit breaker for my application?

To select the right EATON Power Defense circuit breaker, match the continuous current rating (e.g., 30 A), interrupting capacity (e.g., 65kA at 480V AC), trip type (instantaneous), phase connection (ABC), and terminal type (load side lug) to your system's voltage and fault current requirements. Consult a qualified engineer for coordination studies.
