EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 4 unit features a 135 A rating, a 24V AC coil, and includes a pilot…

SKU 3G-OTH-43249

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19NN0T5E140
Type
NEMA Size 4, 135 A
Phase
Three
Poles
3
AC Coil
24V
Operator
None
Coil Voltage
24V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 4 unit features a 135 A rating, a 24V AC coil, and includes a pilot light for signaling. It comes with one normally open (1NO) auxiliary contact and requires no thermal units, as electronic overloads are integrated.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications. Its electronic overloads protect motors from damage due to overcurrent, while the pilot light provides visual status signaling. It is suitable for heavy-duty machinery, pumps, and conveyors.

What are the specifications of the EATON NEMA Magnetic Motor Starter AN19NN0T5E140?

This EATON starter is a non-reversing, three-pole, NEMA Size 4 unit rated at 135 A with a 24V AC coil. It includes one normally open auxiliary contact and an integrated pilot light. Electronic overloads eliminate the need for separate thermal units. The phase is three-phase.

Where to buy the EATON NEMA Magnetic Motor Starter AN19NN0T5E140 worldwide?

3G Electric supplies the EATON NEMA Magnetic Motor Starter AN19NN0T5E140 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this EATON motor starter.

How to install the EATON NEMA Magnetic Motor Starter?

Installation should follow the manufacturer's wiring diagram and local electrical codes. Mount the starter on a flat surface, connect the three-phase power and motor leads to the appropriate terminals, and wire the 24V AC coil to the control circuit. Ensure the electronic overload is set to the motor's full-load current.
