EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, featuring three poles, NEMA Size 1, and a 27 A rating. It operates with a 220/240V AC coil voltage and includes a pilot…

SKU 3G-OTH-42377

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19DN0B5E045
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
240V
Operator
None
Coil Voltage
220/240V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, featuring three poles, NEMA Size 1, and a 27 A rating. It operates with a 220/240V AC coil voltage and includes a pilot light and one normally open auxiliary contact. This three-phase starter has no operator or operator controls, and thermal units are not applicable due to the electronic overload design.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used to start and stop three-phase AC motors in industrial applications. Its non-reversing design and electronic overload protection make it suitable for conveyors, pumps, and fans where motor direction is fixed.

What are the specifications of the EATON AN19DN0B5E045 motor starter?

This EATON starter is NEMA Size 1, rated 27 A, with three poles and a 220/240V AC coil. It includes a pilot light and one normally open auxiliary contact. Electronic overloads eliminate the need for thermal units. It is a non-reversing, three-phase unit.

Where to buy the EATON AN19DN0B5E045 motor starter worldwide?

3G Electric supplies the EATON AN19DN0B5E045 motor starter worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this NEMA Size 1 starter.

How to select the correct NEMA motor starter size for a motor?

Select a NEMA starter size based on the motor's full-load current and voltage. For a 27 A, 240V AC three-phase motor, a NEMA Size 1 starter like this EATON model is appropriate. Always verify the coil voltage matches your control circuit and that overload protection is properly set.
