EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 1 unit features a 27 A rating and a 110/120V AC coil, with a 1NO…

SKU 3G-OTH-41962

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19DN0A5E020
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
120V
Operator
None
Coil Voltage
110/120V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 1 unit features a 27 A rating and a 110/120V AC coil, with a 1NO auxiliary contact form and an included pilot light for signaling. It requires no thermal units, as electronic overloads are integrated.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

This EATON non-reversing starter with electronic overloads controls three-phase motors up to 27 A in industrial applications like conveyors, pumps, and compressors. Its NEMA Size 1 design and 120V AC coil suit heavy-duty environments requiring reliable starting and overload protection.

What are the specifications of the EATON AN19DN0A5E020 motor starter?

The EATON AN19DN0A5E020 is a NEMA Size 1, 27 A, three-phase, non-reversing starter with a 110/120V AC coil. It includes one normally open auxiliary contact and an integrated pilot light. Electronic overloads eliminate the need for thermal units, simplifying setup.

Where to buy the EATON NEMA Magnetic Motor Starter worldwide?

3G Electric supplies the EATON AN19DN0A5E020 motor starter to global customers. We handle full logistics, customs clearance, and delivery to your site worldwide. Contact us for a quote and lead time on this NEMA Size 1, 27 A unit.

How to install the EATON NEMA Magnetic Motor Starter?

Mount the starter on a flat surface, connect three-phase power to the line terminals, and wire the motor to the load terminals. Apply 120V AC to the coil terminals for control. Follow EATON’s manual for torque settings and electronic overload adjustment.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Products

3G Electric supplies EATON non-reversing starters with electronic overloads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
