EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit features a 27 A rating, a 110/120V AC coil, and includes a…

SKU 3G-OTH-41920

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19DN0A5E005
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
120V
Operator
None
Coil Voltage
110/120V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit features a 27 A rating, a 110/120V AC coil, and includes a pilot light and one normally open auxiliary contact. It is supplied without an operator or operator controls, and thermal units are not applicable due to the electronic overload design.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications. It provides overload protection via its electronic overload, making it suitable for pumps, fans, conveyors, and compressors where non-reversing motor control is required.

What are the specifications of the EATON AN19DN0A5E005 motor starter?

The EATON AN19DN0A5E005 is a NEMA Size 1, non-reversing magnetic motor starter rated for 27 A at 110/120V AC coil voltage. It includes a pilot light and one normally open auxiliary contact. It is a three-phase unit with an electronic overload, so no thermal units are required.

Where to buy the EATON AN19DN0A5E005 motor starter worldwide?

You can source the EATON AN19DN0A5E005 motor starter from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this EATON part.

How to select the correct NEMA size for an EATON motor starter?

Select the NEMA size based on the motor's full-load current and voltage. For the EATON AN19DN0A5E005, NEMA Size 1 covers up to 27 A for three-phase motors. Always match the coil voltage (110/120V AC) to your control circuit and ensure the electronic overload is set per motor nameplate data.
