EATON Plunger Limit Switch: Plunger Actuator, Maintained, Metallic, 8 ozf Op Force - Min
The EATON E50AH1 is a side-mount plunger limit switch from the E50 Series, featuring a metallic body and a plunger actuator. It operates with a maintained action and includes screw terminals for electrical…
SKU 3G-OTH-29925
Need installation or engineering help?
Ask a question
Product Description
The EATON E50AH1 is a side-mount plunger limit switch from the E50 Series, featuring a metallic body and a plunger actuator. It operates with a maintained action and includes screw terminals for electrical connection, with a minimum operating force of 8 ozf.
Frequently Asked Questions
What is the EATON E50AH1 plunger limit switch used for?
The EATON E50AH1 is a side-mount plunger limit switch used in industrial automation to detect the presence or position of moving parts. Its maintained action and metallic body suit heavy-duty applications such as conveyor systems, packaging machinery, and material handling equipment where reliable position sensing is required.
What are the specifications of the EATON E50AH1 limit switch?
The EATON E50AH1 is a maintained-action limit switch from the E50 Series with a plunger actuator and metallic body. It features screw terminals for electrical connection and requires a minimum operating force of 8 ozf. The manufacturer part number is E50AH1.
Where to buy the EATON E50AH1 limit switch worldwide?
You can source the EATON E50AH1 limit switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this EATON E50 Series component.
How to install the EATON E50AH1 plunger limit switch?
Mount the EATON E50AH1 securely using the side-mount holes, ensuring the plunger aligns with the target. Connect wiring to the screw terminals per your control circuit. Adjust the actuator position so the plunger depresses fully during operation. Test the maintained action before finalizing installation.
Used in
Common applications for EATONEATON Products
3G Electric supplies EATON side-mount plunger limit switches. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
