EATON Plunger Limit Switch: Plunger Actuator, Maintained, Metallic, 8 ozf Op Force - Min
The EATON E50BH1 is a side-mount plunger limit switch from the E50 Series, featuring a metallic body and a plunger actuator. It operates with a maintained action and requires a minimum operating force of 8 ozf…
SKU 3G-OTH-29982
Need installation or engineering help?
Ask a question
Product Description
The EATON E50BH1 is a side-mount plunger limit switch from the E50 Series, featuring a metallic body and a plunger actuator. It operates with a maintained action and requires a minimum operating force of 8 ozf. Electrical connection is via screw terminals.
Frequently Asked Questions
What is the EATON E50BH1 plunger limit switch used for?
The EATON E50BH1 is a side-mount plunger limit switch used in industrial automation to detect the presence or position of moving parts. Its maintained action holds the circuit state until manually reset, making it suitable for safety interlocks and machine guarding applications across manufacturing and material handling.
What are the specifications of the EATON E50BH1 limit switch?
The EATON E50BH1 is a metallic-bodied limit switch with a plunger actuator and maintained action. It requires a minimum operating force of 8 ozf and connects via screw terminals. It is part of the E50 Series and is designed for side-mount installation in industrial environments.
Where to buy the EATON E50BH1 limit switch worldwide?
3G Electric supplies the EATON E50BH1 limit switch to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this E50 Series component.
How to install the EATON E50BH1 plunger limit switch?
Mount the EATON E50BH1 securely on a flat surface using the side-mount holes. Connect wiring to the screw terminals per your control circuit diagram. Ensure the plunger aligns with the cam or actuator for reliable maintained-action operation. Test the switch before placing the machine into service.
Used in
Common applications for EATONEATON Products
3G Electric supplies EATON side-mount plunger limit switches. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
