EATON Plunger Limit Switch: Plunger Actuator, Maintained, Metallic, 8 ozf Op Force - Min
The EATON E50AH16P is a side-mount plunger limit switch from the E50 series, featuring a metallic body and a plunger actuator. It operates with maintained action and includes an 8 ft cable for electrical connection…
SKU 3G-OTH-29974
Need installation or engineering help?
Ask a question
Product Description
The EATON E50AH16P is a side-mount plunger limit switch from the E50 series, featuring a metallic body and a plunger actuator. It operates with maintained action and includes an 8 ft cable for electrical connection. This switch requires a minimum operating force of 8 ozf.
Frequently Asked Questions
What is the EATON E50AH16P plunger limit switch used for?
The EATON E50AH16P is a side-mount plunger limit switch used in industrial automation to detect the presence or position of moving parts. Its maintained action keeps the circuit state until manually reset, making it suitable for safety interlocks and machine guarding in manufacturing and material handling.
What are the specifications of the EATON E50AH16P limit switch?
The EATON E50AH16P is a metallic-bodied, plunger-actuated limit switch from the E50 series. It features maintained action, an 8 ft cable for electrical connection, and requires a minimum operating force of 8 ozf. The manufacturer part number is E50AH16P.
Where to buy the EATON E50AH16P limit switch worldwide?
3G Electric supplies the EATON E50AH16P limit switch to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this E50 series plunger switch.
How to install the EATON E50AH16P plunger limit switch?
Mount the EATON E50AH16P securely using the side-mount holes, ensuring the plunger aligns with the cam or actuator. Connect the 8 ft cable per the wiring diagram, verify the maintained action operates correctly, and test the minimum 8 ozf operating force before putting the machine into service.
Used in
Common applications for EATONEATON Products
3G Electric supplies EATON side-mount plunger limit switches. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
