EATON Circuit Breaker: 25 A, 120/240V AC, Single Phase, 10kA at 120/240V AC - BR & BD Series
EATONBR & BD Series

EATON Circuit Breaker: 25 A, 120/240V AC, Single Phase, 10kA at 120/240V AC

The EATON BR225 is a standard circuit breaker from the BR & BD Series, rated for 25 A at 120/240V AC single phase with a maximum AIR rating of 10kA at 120/240V AC. Designed for use with Type BR loadcenters, this…

SKU 3G-OTH-23136

Brand
EATON
Item
Circuit Breaker: 25 A, 120/240V AC, Single Phase, 10kA at 120/240V AC
Category
BR & BD Series
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
BR225
Type
Single Phase, 10kA at 120/240V AC, Type BR Loadcenters
AC
120/240V
Amps
25 A
Phase
Single
For Use With
Type BR Loadcenters
Max. AIR Rating
10kA at 120/240V AC
AC Voltage Rating
120/240V AC
Circuit Breaker Type
Standard
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON BR225 is a standard circuit breaker from the BR & BD Series, rated for 25 A at 120/240V AC single phase with a maximum AIR rating of 10kA at 120/240V AC. Designed for use with Type BR loadcenters, this single-phase breaker provides overcurrent protection in residential and commercial electrical distribution systems.

Frequently Asked Questions

What is the EATON BR225 circuit breaker used for?

The EATON BR225 provides overcurrent protection in residential and commercial electrical distribution systems. It is designed for use with Type BR loadcenters, protecting branch circuits rated 25 A at 120/240V AC single phase.

What are the specifications of the EATON BR225?

The EATON BR225 is a standard single-phase circuit breaker rated 25 A at 120/240V AC, with a maximum AIR rating of 10kA at 120/240V AC. It is designed for use with Type BR loadcenters and is part of the BR & BD Series from EATON.

Where to buy the EATON BR225 worldwide?

3G Electric supplies the EATON BR225 worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the EATON BR225 circuit breaker?

To install the EATON BR225, ensure the loadcenter is de-energized. Snap the breaker firmly onto the bus bar of a Type BR loadcenter, then connect the circuit wires to the terminal. Follow local electrical codes and use appropriate personal protective equipment.
