EATON Circuit Breaker: 20 A Amps, 25 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 20 A Amps, 25 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT42, MPN PDG13F0020TFFJ) is a 20 A, 3-pole unit with a 125A/Frame 1 frame size. It features a maximum AIR rating of 25 kA at 480V AC, a fixed instantaneous…

SKU 3G-OTH-23584

Brand
EATON
Item
Circuit Breaker: 20 A Amps, 25 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG13F0020TFFJ
Type
25 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs, Std
Poles
3
Frame Size
125A/Frame 1
Max. AIR Rating
25 kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Standard Line and Load Lugs
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT42, MPN PDG13F0020TFFJ) is a 20 A, 3-pole unit with a 125A/Frame 1 frame size. It features a maximum AIR rating of 25 kA at 480V AC, a fixed instantaneous trip, and ABC phase connection. Terminal connection is via standard line and load lugs.

Frequently Asked Questions

What is the EATON Power Defense molded case circuit breaker used for?

The EATON Power Defense molded case circuit breaker protects electrical circuits from overloads and short circuits in industrial and commercial power distribution systems. It is suitable for panelboards, switchboards, and motor control centers requiring a 20 A, 3-pole breaker with a 25 kA interrupting rating at 480V AC.

What are the specifications of the EATON PDG13F0020TFFJ circuit breaker?

The EATON PDG13F0020TFFJ is a 20 A, 3-pole Power Defense molded case circuit breaker with a 125A/Frame 1 frame size. It has a maximum AIR rating of 25 kA at 480V AC, fixed instantaneous trip, ABC phase connection, and standard line and load lugs for terminal connection.

Where to buy the EATON PDG13F0020TFFJ circuit breaker worldwide?

3G Electric supplies the EATON PDG13F0020TFFJ circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this 20 A, 3-pole Power Defense breaker.

How to select the correct EATON Power Defense circuit breaker for your application?

To select the correct EATON Power Defense breaker, verify your system voltage (480V AC), required amp rating (20 A), number of poles (3), and interrupting capacity (25 kA). Confirm phase connection (ABC) and terminal type (standard lugs). Consult a licensed electrician and refer to the NEC for proper coordination and installation.
