EATON Circuit Breaker: 30 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 30 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT88, MPN PDG22G0030TFFL) is a 30 A, 2-pole unit with a 225A/Frame 2 frame size. It features a maximum AIR rating of 35 kA at 480V AC, a fixed instantaneous…

SKU 3G-OTH-24321

Brand
EATON
Item
Circuit Breaker: 30 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG22G0030TFFL
Type
35 kA at 480V AC, Fixed, AB, Std Terminals Load Only, Std
Poles
2
Frame Size
225A/Frame 2
Max. AIR Rating
35 kA at 480V AC
Phase Connection
AB
Instantaneous Trip
Fixed
Terminal Connection
Standard Terminals Load Only
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT88, MPN PDG22G0030TFFL) is a 30 A, 2-pole unit with a 225A/Frame 2 frame size. It features a maximum AIR rating of 35 kA at 480V AC, a fixed instantaneous trip, and AB phase connection. The breaker includes standard terminals load only for terminal connection.

Frequently Asked Questions

What is the EATON PDG22G0030TFFL circuit breaker used for?

The EATON Power Defense molded case circuit breaker (PDG22G0030TFFL) protects electrical circuits from overloads and short circuits in commercial and industrial applications. Its 30 A rating and 35 kA interrupting capacity at 480V AC suit motor control centers, panelboards, and distribution systems requiring AB phase connection.

What are the specifications of the EATON PDG22G0030TFFL?

This 2-pole breaker has a 30 A amp rating, 35 kA maximum AIR at 480V AC, and a 225A/Frame 2 frame size. It features a fixed instantaneous trip, AB phase connection, and standard terminals load only. The manufacturer part number is PDG22G0030TFFL.

Where to buy the EATON PDG22G0030TFFL worldwide?

3G Electric supplies the EATON PDG22G0030TFFL circuit breaker worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to select the right EATON Power Defense circuit breaker?

Select based on system voltage, continuous current (30 A), interrupting capacity (35 kA at 480V AC), pole count (2), and trip type (fixed instantaneous). Verify phase connection (AB) and terminal configuration (standard load only). Consult EATON's application guide for coordination and compliance.
