EATON Circuit Breaker: 15 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 15 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT85, MPN PDG22G0015TFFL) is a 15 A, 2-pole unit with a 225A/Frame 2 frame size. It features a fixed instantaneous trip, a maximum AIR rating of 35 kA at…

SKU 3G-OTH-24512

Brand
EATON
Item
Circuit Breaker: 15 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG22G0015TFFL
Type
35 kA at 480V AC, Fixed, AB, Std Terminals Load Only, Std
Poles
2
Frame Size
225A/Frame 2
Max. AIR Rating
35 kA at 480V AC
Phase Connection
AB
Instantaneous Trip
Fixed
Terminal Connection
Standard Terminals Load Only
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT85, MPN PDG22G0015TFFL) is a 15 A, 2-pole unit with a 225A/Frame 2 frame size. It features a fixed instantaneous trip, a maximum AIR rating of 35 kA at 480V AC, AB phase connection, and standard terminals load only.

Frequently Asked Questions

What is the EATON PDG22G0015TFFL circuit breaker used for?

The EATON Power Defense molded case circuit breaker (PDG22G0015TFFL) protects electrical circuits from overloads and short circuits in industrial and commercial power distribution systems. It is suitable for applications requiring a 15 A, 2-pole breaker with a 35 kA interrupting rating at 480V AC.

What are the specifications of the EATON PDG22G0015TFFL?

This EATON circuit breaker has a 15 A rating, 2 poles, a 225A/Frame 2 frame size, and a maximum AIR rating of 35 kA at 480V AC. It features a fixed instantaneous trip, AB phase connection, and standard terminals load only. The MPN is PDG22G0015TFFL.

Where to buy the EATON PDG22G0015TFFL worldwide?

3G Electric supplies the EATON PDG22G0015TFFL circuit breaker worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the right EATON Power Defense circuit breaker?

Select based on required amperage, pole count, interrupting rating, and trip type. For the PDG22G0015TFFL, confirm 15 A, 2 poles, 35 kA at 480V AC, and fixed instantaneous trip meet your system's fault current and coordination needs. Consult a licensed engineer for proper application.
