EATON Circuit Breaker: 100 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 100 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT95, MPN PDG22G0100TFFL) is a 100 A rated device with a 225A/Frame 2 frame size. It features a maximum AIR rating of 35 kA at 480V AC, a fixed instantaneous…

SKU 3G-OTH-24006

Brand
EATON
Item
Circuit Breaker: 100 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG22G0100TFFL
Type
35 kA at 480V AC, Fixed, AB, Std Terminals Load Only, Std
Frame Size
225A/Frame 2
Max. AIR Rating
35 kA at 480V AC
Phase Connection
AB
Instantaneous Trip
Fixed
Terminal Connection
Standard Terminals Load Only
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT95, MPN PDG22G0100TFFL) is a 100 A rated device with a 225A/Frame 2 frame size. It features a maximum AIR rating of 35 kA at 480V AC, a fixed instantaneous trip, and AB phase connection. The breaker includes standard terminals for load-only connection.

Frequently Asked Questions

What is the EATON Power Defense molded case circuit breaker used for?

The EATON Power Defense molded case circuit breaker is used for overcurrent protection in industrial and commercial electrical distribution systems. It safeguards branch circuits, feeders, and equipment from short circuits and overloads, with a 100 A rating and 35 kA interrupting capacity at 480V AC.

What are the specifications of the EATON PDG22G0100TFFL circuit breaker?

The EATON PDG22G0100TFFL is a 100 A Power Defense molded case circuit breaker with a 225A/Frame 2 frame size. It has a maximum AIR rating of 35 kA at 480V AC, fixed instantaneous trip, AB phase connection, and standard terminals for load-only connection.

Where to buy the EATON PDG22G0100TFFL circuit breaker worldwide?

You can source the EATON PDG22G0100TFFL circuit breaker through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring compliance and reliable supply for your project needs.

How to select the correct EATON Power Defense circuit breaker for your application?

To select the correct EATON Power Defense circuit breaker, verify the continuous current rating (100 A), interrupting capacity (35 kA at 480V AC), and frame size (225A/Frame 2). Ensure the phase connection (AB) and terminal type (standard load-only) match your panel and load requirements.
