GE Miniature Circuit Breaker: THHQL, 100 A, 120/240V AC, Single Phase, 22kA at 120/240V AC - THQP, THQL & THHQL Series, Plug-In GE Miniature Circuit Breakers
GETHQP, THQL & THHQL Series, Plug-In GE Miniature Circuit Breakers

GE Miniature Circuit Breaker: THHQL, 100 A, 120/240V AC, Single Phase, 22kA at 120/240V AC

The GE THHQL is a 100 A, single-phase, 2-pole miniature circuit breaker from the THQP, THQL & THHQL Series. It is rated for 120/240V AC with a maximum AIR rating of 22kA at 120/240V AC. This plug-in breaker is…

SKU 3G-OTH-22094

Brand
GE
Item
Miniature Circuit Breaker: THHQL, 100 A, 120/240V AC, Single Phase, 22kA at 120/240V AC
Category
THQP, THQL & THHQL Series, Plug-In GE Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
THHQL21100
Type
100 A, Single Phase, 22kA at 120/240V AC
AC
120/240V
Amps
100 A
Phase
Single
Poles
2
For Use With
Power Mark Gold Load Centers and AQ Lighting Panels
Max. AIR Rating
22kA at 120/240V AC
AC Voltage Rating
120/240V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE THHQL is a 100 A, single-phase, 2-pole miniature circuit breaker from the THQP, THQL & THHQL Series. It is rated for 120/240V AC with a maximum AIR rating of 22kA at 120/240V AC. This plug-in breaker is designed for use with Power Mark Gold Load Centers and AQ Lighting Panels.

Frequently Asked Questions

What is the GE THHQL21100 miniature circuit breaker used for?

The GE THHQL21100 is a 100 A, 2-pole miniature circuit breaker used for overcurrent protection in single-phase 120/240V AC electrical systems. It is designed for plug-in installation in Power Mark Gold Load Centers and AQ Lighting Panels, making it suitable for commercial and industrial branch circuit protection.

What are the specifications of the GE THHQL21100 circuit breaker?

The GE THHQL21100 is rated 100 A at 120/240V AC, single-phase, with a maximum AIR rating of 22kA at 120/240V AC. It has 2 poles and is a plug-in type from the THHQL series. It is compatible with Power Mark Gold Load Centers and AQ Lighting Panels.

Where to buy the GE THHQL21100 circuit breaker worldwide?

3G Electric supplies the GE THHQL21100 miniature circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this genuine GE breaker for your project.

How to install the GE THHQL21100 circuit breaker?

To install the GE THHQL21100, ensure the load center is de-energized. Align the breaker's plug-in tabs with the bus bar slots in a compatible Power Mark Gold Load Center or AQ Lighting Panel, then press firmly until it snaps into place. Always follow local electrical codes and use proper personal protective equipment.
