GE Miniature Circuit Breaker: THHQL, 30 A, 120/240V AC, Single Phase, 22kA at 120/240V AC - THQP, THQL & THHQL Series, Plug-In GE Miniature Circuit Breakers
GETHQP, THQL & THHQL Series, Plug-In GE Miniature Circuit Breakers

GE Miniature Circuit Breaker: THHQL, 30 A, 120/240V AC, Single Phase, 22kA at 120/240V AC

The GE THHQL2130 is a 2-pole, single-phase miniature circuit breaker from the THQP, THQL & THHQL Series, rated at 30 A and 120/240V AC with a maximum AIR rating of 22kA at 120/240V AC. It is designed for use with…

SKU 3G-OTH-22434

Brand
GE
Item
Miniature Circuit Breaker: THHQL, 30 A, 120/240V AC, Single Phase, 22kA at 120/240V AC
Category
THQP, THQL & THHQL Series, Plug-In GE Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
THHQL2130
Type
30 A, Single Phase, 22kA at 120/240V AC
AC
120/240V
Amps
30 A
Phase
Single
Poles
2
For Use With
Power Mark Gold Load Centers and AQ Lighting Panels
Max. AIR Rating
22kA at 120/240V AC
AC Voltage Rating
120/240V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE THHQL2130 is a 2-pole, single-phase miniature circuit breaker from the THQP, THQL & THHQL Series, rated at 30 A and 120/240V AC with a maximum AIR rating of 22kA at 120/240V AC. It is designed for use with Power Mark Gold Load Centers and AQ Lighting Panels.

Frequently Asked Questions

What is the GE THHQL2130 miniature circuit breaker used for?

The GE THHQL2130 is a 2-pole miniature circuit breaker rated 30 A at 120/240V AC, single phase. It provides overcurrent protection for branch circuits in Power Mark Gold Load Centers and AQ Lighting Panels. Common applications include residential and light commercial electrical distribution systems.

What are the specifications of the GE THHQL2130 circuit breaker?

The GE THHQL2130 is a 2-pole, single-phase miniature circuit breaker rated 30 A and 120/240V AC. It has a maximum AIR rating of 22kA at 120/240V AC. It is designed for use with Power Mark Gold Load Centers and AQ Lighting Panels. The manufacturer part number is THHQL2130.

Where to buy the GE THHQL2130 circuit breaker worldwide?

3G Electric supplies the GE THHQL2130 miniature circuit breaker worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this GE breaker to customers internationally.

How to install the GE THHQL2130 circuit breaker?

To install the GE THHQL2130, ensure the load center is de-energized. Plug the breaker firmly onto the bus bar until it snaps into place. Connect the load wire to the terminal and torque to the manufacturer's specification. Verify the breaker is rated for the panel type, such as Power Mark Gold Load Centers.
