GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC - USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
GRACOUSP Class VI-Compliant Pharmaceutical-Grade EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC

The GRACO Electric Diaphragm Pump with Stainless Steel Body (MPN HE120-1401) is a USP Class VI-compliant pharmaceutical-grade EODD pump. It features a 316 SS seat material, PTFE check valves, and PTFE diaphragms with…

SKU 3G-OTH-85750

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC
Category
USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE120-1401
Type
Three Phase, 2 in
AC
380-480V
Max. Head
29 ft
Seat Material
316 SS
Nameplate Voltage
380-480V AC
Surface Roughness
20 Ra
Diaphragm Material
PTFE with Santoprene Backing
Check Valve Material
PTFE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump with Stainless Steel Body (MPN HE120-1401) is a USP Class VI-compliant pharmaceutical-grade EODD pump. It features a 316 SS seat material, PTFE check valves, and PTFE diaphragms with Santoprene backing, with a surface roughness of 20 Ra. The pump operates on three-phase 380-480V AC power and delivers a 2-inch port size with a 29 ft maximum head.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE120-1401 used for?

This GRACO pump is a USP Class VI-compliant pharmaceutical-grade EODD pump, designed for hygienic transfer of sensitive fluids in biopharma, food, and cosmetic applications. Its 316 SS seat, PTFE check valves, and 20 Ra surface finish meet strict cleanability and purity standards.

What are the specifications of the GRACO HE120-1401 pump?

The GRACO HE120-1401 is a three-phase electric diaphragm pump with a 2-inch port, 29 ft max head, and 380-480V AC power. It features a 316 SS seat, PTFE check valves, and PTFE diaphragms with Santoprene backing, with a surface roughness of 20 Ra for pharmaceutical-grade service.

Where to buy the GRACO HE120-1401 pump worldwide?

3G Electric supplies the GRACO HE120-1401 pump to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this USP Class VI-compliant pharmaceutical-grade EODD pump.

How to select the right GRACO electric diaphragm pump for pharmaceutical use?

For pharmaceutical applications, select a pump with USP Class VI compliance, such as the GRACO HE120-1401. Verify wetted materials (316 SS, PTFE), surface finish (20 Ra or better), and port size match your flow and head requirements. Confirm power supply matches your 380-480V AC three-phase system.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
