GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC - USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
GRACOUSP Class VI-Compliant Pharmaceutical-Grade EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC

The GRACO Electric Diaphragm Pump (SKU 411VX4, MPN HE80-1404) is a USP Class VI-compliant pharmaceutical-grade EODD pump with a stainless steel body. It features a 380-480V AC three-phase motor, 316 SS seat material…

SKU 3G-OTH-85873

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC
Category
USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE80-1404
Type
Three Phase, 1 1/2 in, PTFE Valve
AC
380-480V
Seat Material
316 SS
Nameplate Voltage
380-480V AC
Surface Roughness
20 Ra
Diaphragm Material
PTFE with EPDM Backing
Check Valve Material
PTFE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump (SKU 411VX4, MPN HE80-1404) is a USP Class VI-compliant pharmaceutical-grade EODD pump with a stainless steel body. It features a 380-480V AC three-phase motor, 316 SS seat material, PTFE check valves, and a PTFE diaphragm with EPDM backing, with a surface roughness of 20 Ra.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE80-1404 used for?

This GRACO EODD pump is designed for pharmaceutical and bioprocessing applications requiring USP Class VI compliance. Its stainless steel body, 20 Ra surface finish, and PTFE wetted parts make it suitable for transferring sterile fluids, solvents, and aggressive chemicals in cleanroom environments.

What are the specifications of the GRACO HE80-1404 pump?

The GRACO HE80-1404 is a three-phase electric diaphragm pump with a 380-480V AC motor, 1 1/2 in inlet/outlet, 316 SS seat material, PTFE check valves, and a PTFE diaphragm with EPDM backing. Surface roughness is 20 Ra. It is USP Class VI-compliant for pharmaceutical use.

Where to buy the GRACO HE80-1404 pump worldwide?

3G Electric supplies the GRACO HE80-1404 pump worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on this USP Class VI-compliant EODD pump.

How to select the right GRACO electric diaphragm pump?

Select based on fluid compatibility, pressure, and flow requirements. For pharmaceutical use, ensure USP Class VI compliance and surface finish (20 Ra). The HE80-1404 with PTFE valves and 316 SS seats suits aggressive chemicals. Verify voltage (380-480V AC) and connection size (1 1/2 in) match your system.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
