GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC - USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
GRACOUSP Class VI-Compliant Pharmaceutical-Grade EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC

The GRACO Electric Diaphragm Pump (MPN HE30-1404) is a USP Class VI-compliant pharmaceutical-grade EODD pump with a stainless steel body. It features a 380-480V AC three-phase motor, 1-inch ports, and a 29 ft maximum…

SKU 3G-OTH-85740

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC
Category
USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE30-1404
Type
Three Phase, 1 in
AC
380-480V
Max. Head
29 ft
Seat Material
316 SS
Nameplate Voltage
380-480V AC
Surface Roughness
20 Ra
Diaphragm Material
PTFE with EPDM Backing
Check Valve Material
PTFE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump (MPN HE30-1404) is a USP Class VI-compliant pharmaceutical-grade EODD pump with a stainless steel body. It features a 380-480V AC three-phase motor, 1-inch ports, and a 29 ft maximum head. Key specifications include a 20 Ra surface roughness, PTFE check valves, PTFE diaphragms with EPDM backing, and 316 SS seat material.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE30-1404 used for?

The GRACO Electric Diaphragm Pump HE30-1404 is a USP Class VI-compliant pharmaceutical-grade EODD pump used for transferring sensitive fluids in biopharma, food, and cosmetic processing. Its 20 Ra surface finish and PTFE wetted parts meet clean-in-place requirements.

What are the specifications of the GRACO HE30-1404 pump?

The GRACO HE30-1404 pump has a 380-480V AC three-phase motor, 1-inch ports, and a 29 ft maximum head. It features a 316 SS seat, PTFE check valves, and PTFE diaphragms with EPDM backing. Surface roughness is 20 Ra, and the body is stainless steel.

Where to buy the GRACO HE30-1404 pump worldwide?

You can source the GRACO HE30-1404 pump through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the right GRACO electric diaphragm pump?

Select based on fluid compatibility, required flow rate, and pressure. For the HE30-1404, ensure your power supply matches 380-480V AC three-phase. Verify port size (1 inch) and wetted materials (PTFE, 316 SS) suit your process. Consult GRACO's technical data for duty cycle limits.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
