HAYWARD Diaphragm Valve: 1 in, CPVC, 2-Way, NPT x Socket, 150 psi Max Pressure (CWP) - CPVC Diaphragm Valves for Chemicals with Position Indicators
HAYWARDCPVC Diaphragm Valves for Chemicals with Position Indicators

HAYWARD Diaphragm Valve: 1 in, CPVC, 2-Way, NPT x Socket, 150 psi Max Pressure (CWP)

The HAYWARD Diaphragm Valve is a 1-inch CPVC diaphragm valve for chemicals, featuring a position indicator. This 2-way valve has NPT x Socket connections and a maximum pressure rating of 150 psi (CWP). It is equipped…

SKU 3G-OTH-448621

Brand
HAYWARD
Item
Diaphragm Valve: 1 in, CPVC, 2-Way, NPT x Socket, 150 psi Max Pressure
Category
CPVC Diaphragm Valves for Chemicals with Position Indicators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAYWARD
Manufacturer Part Number
DAB2010UFF
Type
CPVC, 2-Way, NPT x Socket, FPM
Special Features
Position Indicator
Diaphragm Material
FPM
Max Pressure (CWP)
150 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAYWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAYWARD Diaphragm Valve is a 1-inch CPVC diaphragm valve for chemicals, featuring a position indicator. This 2-way valve has NPT x Socket connections and a maximum pressure rating of 150 psi (CWP). It is equipped with an FPM diaphragm (MPN DAB2010UFF).

Frequently Asked Questions

What is the HAYWARD CPVC diaphragm valve used for?

The HAYWARD CPVC diaphragm valve is used for on-off or throttling control of corrosive chemicals in industrial processes. Its CPVC body resists acids, bases, and solvents, while the FPM diaphragm provides chemical compatibility. The position indicator allows visual confirmation of valve status, making it suitable for chemical processing, water treatment, and plating applications.

What are the specifications of the HAYWARD diaphragm valve DAB2010UFF?

The HAYWARD diaphragm valve DAB2010UFF has a 1-inch CPVC body, 2-way configuration, and NPT x Socket connections. It features an FPM diaphragm, a maximum pressure rating of 150 psi (CWP), and a position indicator for visual open/closed status. The valve is designed for chemical service and is manufactured by HAYWARD.

Where to buy HAYWARD diaphragm valves worldwide?

You can source HAYWARD diaphragm valves worldwide through 3G Electric, a global industrial equipment distributor established in 1990. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on the HAYWARD DAB2010UFF or other CPVC diaphragm valves.

How to install a HAYWARD CPVC diaphragm valve?

Install the HAYWARD CPVC diaphragm valve by aligning the socket or NPT connections with matching pipe ends. Use CPVC-compatible solvent cement for socket joints or PTFE tape for threaded connections. Support the valve body to avoid stress on piping. Cycle the valve fully open and closed to verify the position indicator functions correctly before pressurizing the system.

Used in

Common applications for HAYWARD
Chemical processing — Hayward CPVC butterfly valves (PCSBYV series) for corrosive chemical flow control
Water treatment — Hayward glass-filled polypropylene butterfly valves (BYV series) for general-service water lines
Industrial filtration — Hayward CPVC Y strainers (YS series) for removing particulates from process fluids
Automated valve control — Hayward pneumatic actuators (PSD series) for remote operation of quarter-turn valves
Solenoid valve applications — Hayward 2-way solenoid valves (SV series) for on/off control of water or mild chemicals

HAYWARD Products

3G Electric supplies HAYWARD cpvc diaphragm valves for chemicals with position indicators. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
