Honeywell Miniature Snap Action Switch: Roller Lever Actuator, 1NO/1NC
The HONEYWELL V15W-DZ200A04-W2 is a miniature snap-action switch from the V15W series, featuring a simulated roller lever actuator and 1NO/1NC contact configuration. It is rated for 6 A at 125/250 V AC and connects…
SKU 3G-OTH-39253
Need installation or engineering help?
Ask a question
Product Description
The HONEYWELL V15W-DZ200A04-W2 is a miniature snap-action switch from the V15W series, featuring a simulated roller lever actuator and 1NO/1NC contact configuration. It is rated for 6 A at 125/250 V AC and connects via 3/16 in quick-connect terminals.
Frequently Asked Questions
What is the HONEYWELL V15W-DZ200A04-W2 miniature snap action switch used for?
The HONEYWELL V15W-DZ200A04-W2 is a miniature snap-action switch with a simulated roller lever actuator, used for position sensing and limit control in industrial equipment, HVAC systems, and appliances. Its 1NO/1NC contacts and 6 A rating at 125/250 V AC suit it for reliable switching in tight spaces.
What are the specifications of the HONEYWELL V15W-DZ200A04-W2 switch?
The HONEYWELL V15W-DZ200A04-W2 is a miniature snap-action switch from the V15W series. It features a simulated roller lever actuator, 1NO/1NC contact configuration, AC contact rating of 6 A at 125/250 V, and electrical connection via 3/16 in quick-connect terminals. The manufacturer part number is V15W-DZ200A04-W2.
Where to buy the HONEYWELL V15W-DZ200A04-W2 switch worldwide?
You can source the HONEYWELL V15W-DZ200A04-W2 miniature snap-action switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this Honeywell V15W series switch.
How to install the HONEYWELL V15W-DZ200A04-W2 snap action switch?
To install the HONEYWELL V15W-DZ200A04-W2, mount the switch securely using the provided holes, ensuring the roller lever aligns with the actuating cam or mechanism. Connect wires to the 3/16 in quick-connect terminals per your circuit diagram. Verify the 1NO/1NC contacts are correctly wired before applying power.
