Honeywell Miniature Snap Action Switch: Roller Lever Actuator, 1NO/1NC - Roller-Lever Snap-Action Switches
HoneywellRoller-Lever Snap-Action Switches

Honeywell Miniature Snap Action Switch: Roller Lever Actuator, 1NO/1NC

The HONEYWELL V7-2S17D8-201 is a miniature snap action switch with a roller lever actuator, part of the V7 series. It features a 1NO/1NC contact configuration and a quick connect electrical connection. The switch has…

SKU 3G-OTH-37969

Brand
Honeywell
Item
Miniature Snap Action Switch: Roller Lever Actuator, 1NO/1NC
Category
Roller-Lever Snap-Action Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Honeywell
Manufacturer Part Number
V7-2S17D8-201
Series
V7
Type
1NO/1NC, Quick Connect
AC Contact Rating
0.1 A @ 125 V
Electrical Connection
Quick Connect
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Honeywell Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HONEYWELL V7-2S17D8-201 is a miniature snap action switch with a roller lever actuator, part of the V7 series. It features a 1NO/1NC contact configuration and a quick connect electrical connection. The switch has an AC contact rating of 0.1 A at 125 V.

Frequently Asked Questions

What is the HONEYWELL V7-2S17D8-201 miniature snap action switch used for?

The HONEYWELL V7-2S17D8-201 is used for position sensing and limit control in industrial equipment, HVAC systems, and appliances. Its roller lever actuator detects mechanical motion, making it suitable for applications requiring reliable switching at low currents, such as control panels and automation systems.

What are the specifications of the HONEYWELL V7-2S17D8-201 switch?

The HONEYWELL V7-2S17D8-201 is a miniature snap action switch from the V7 series. It has a roller lever actuator, 1NO/1NC contact configuration, and a quick connect electrical connection. Its AC contact rating is 0.1 A at 125 V. The manufacturer part number is V7-2S17D8-201.

Where to buy the HONEYWELL V7-2S17D8-201 switch worldwide?

You can source the HONEYWELL V7-2S17D8-201 switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide reliable sourcing for this Honeywell component.

How to install the HONEYWELL V7-2S17D8-201 roller lever switch?

Mount the HONEYWELL V7-2S17D8-201 securely using the provided holes, ensuring the roller lever aligns with the actuating mechanism. Connect wires to the quick-connect terminals per the 1NO/1NC schematic. Avoid over-travel beyond the switch's rated limit. Test actuation before finalizing installation.
