Honeywell Miniature Snap Action Switch: Roller Lever Actuator, 1NO/1NC
The HONEYWELL Miniature Snap Action Switch with Roller Lever Actuator (MPN V7-1C17D8-263) is a roller-lever snap-action switch from the V7 series. It features a 1NO/1NC contact configuration and an AC contact rating…
SKU 3G-OTH-38463
Need installation or engineering help?
Ask a question
Product Description
The HONEYWELL Miniature Snap Action Switch with Roller Lever Actuator (MPN V7-1C17D8-263) is a roller-lever snap-action switch from the V7 series. It features a 1NO/1NC contact configuration and an AC contact rating of 15 A @ 277 V, with a Quick Connect electrical connection.
Frequently Asked Questions
What is the HONEYWELL V7-1C17D8-263 miniature snap action switch used for?
The HONEYWELL V7-1C17D8-263 is a roller-lever snap action switch used for position sensing and limit control in industrial equipment, conveyors, and packaging machinery. Its 1NO/1NC contacts and 15 A @ 277 V rating make it suitable for switching loads in automation and HVAC systems.
What are the specifications of the HONEYWELL V7-1C17D8-263 switch?
The HONEYWELL V7-1C17D8-263 is a V7 series miniature snap action switch with a roller lever actuator. It has a 1NO/1NC contact configuration, AC contact rating of 15 A @ 277 V, and a quick connect electrical connection. The manufacturer part number is V7-1C17D8-263.
Where to buy the HONEYWELL V7-1C17D8-263 switch worldwide?
You can source the HONEYWELL V7-1C17D8-263 switch from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this Honeywell V7 series switch.
How to install a HONEYWELL V7-1C17D8-263 roller lever switch?
Mount the HONEYWELL V7-1C17D8-263 switch securely using the provided holes, ensuring the roller lever aligns with the cam or actuator. Connect wires to the quick-connect terminals per the 1NO/1NC schematic. Avoid over-travel beyond the switch's rated limit to prevent damage.
