Honeywell Miniature Snap Action Switch: Roller Lever Actuator, 1NO/1NC
The HONEYWELL Miniature Snap Action Switch with Roller Lever Actuator, part of the V7 Series, is a roller-lever snap-action switch featuring a 1NO/1NC contact configuration. It has an AC contact rating of 11 A @ 277…
SKU 3G-OTH-38177
Need installation or engineering help?
Ask a question
Product Description
The HONEYWELL Miniature Snap Action Switch with Roller Lever Actuator, part of the V7 Series, is a roller-lever snap-action switch featuring a 1NO/1NC contact configuration. It has an AC contact rating of 11 A @ 277 V and utilizes a Quick Connect electrical connection. This switch is identified by manufacturer part number V7-1B17D8-022.
Frequently Asked Questions
What is the HONEYWELL V7-1B17D8-022 miniature snap action switch used for?
The HONEYWELL V7-1B17D8-022 miniature snap action switch with roller lever actuator is used for position sensing and limit control in industrial machinery, conveyors, and automation systems. Its 1NO/1NC contact configuration and 11 A @ 277 V rating make it suitable for switching loads in HVAC, packaging, and material handling equipment.
What are the specifications of the HONEYWELL V7-1B17D8-022 switch?
The HONEYWELL V7-1B17D8-022 is a V7 Series miniature snap action switch with a roller lever actuator. It has a 1NO/1NC contact configuration, an AC contact rating of 11 A @ 277 V, and a Quick Connect electrical connection. The manufacturer part number is V7-1B17D8-022.
Where to buy the HONEYWELL V7-1B17D8-022 switch worldwide?
3G Electric supplies the HONEYWELL V7-1B17D8-022 miniature snap action switch to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery for international orders. Contact us for pricing and lead time on this Honeywell V7 Series switch.
How to install the HONEYWELL V7-1B17D8-022 roller lever switch?
Mount the HONEYWELL V7-1B17D8-022 switch securely using the provided mounting holes, ensuring the roller lever aligns with the cam or actuator. Connect wires to the Quick Connect terminals per the 1NO/1NC schematic. Verify the actuator travel and overtravel meet the application requirements before energizing the circuit.
