SCHNEIDER Supplementary Protector: 1 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp - DC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERDC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 1 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 2-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series, with a 1 A amp rating and a C curve type. It is rated for 500V DC and has a…

SKU 3G-OTH-22495

Brand
SCHNEIDER
Item
Supplementary Protector: 1 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp
Category
DC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9U21201
Series
C60H-DC
Type
5kA at 250V DC, Screw Clamp, C60H-DC, C
DC
500V
Curve Type
C
Max. AIR Rating
5kA at 250V DC
AC Voltage Rating
Not Rated
DC Voltage Rating
500V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 2-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series, with a 1 A amp rating and a C curve type. It is rated for 500V DC and has a maximum AIR rating of 5kA at 250V DC, with screw clamp terminals. This device is not rated for AC voltage.

Frequently Asked Questions

What is the SCHNEIDER C60H-DC supplementary protector used for?

The SCHNEIDER C60H-DC supplementary protector is used to protect DC circuits from overcurrent and short circuits in industrial control panels, solar arrays, and battery systems. It is a 2-pole UL1077 device rated for 500V DC with a 1 A C-curve trip characteristic, suitable for DC-only applications.

What are the specifications of the SCHNEIDER M9U21201?

The SCHNEIDER M9U21201 is a 1 A, 2-pole supplementary protector from the C60H-DC series. It has a DC voltage rating of 500V DC, a maximum AIR rating of 5kA at 250V DC, and screw clamp terminals. It is not rated for AC voltage and features a C curve type for moderate inrush currents.

Where to buy the SCHNEIDER C60H-DC supplementary protector worldwide?

You can source the SCHNEIDER C60H-DC supplementary protector through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this DC-rated protector.

How to install a SCHNEIDER C60H-DC supplementary protector?

Install the SCHNEIDER C60H-DC protector by snapping it onto a DIN rail. Ensure the DC supply is off, then connect wires to the screw clamp terminals per the wiring diagram. Torque terminals to the manufacturer's specification. This device is for DC circuits only and must not be used on AC systems.
