SCHNEIDER Supplementary Protector: 4 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp - DC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERDC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 4 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 2-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series, with a 4 A amp rating and a C curve type. It is rated for 500V DC with a…

SKU 3G-OTH-22512

Brand
SCHNEIDER
Item
Supplementary Protector: 4 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp
Category
DC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9U21204
Series
C60H-DC
Type
5kA at 250V DC, Screw Clamp, C60H-DC, C
DC
500V
Curve Type
C
Max. AIR Rating
5kA at 250V DC
AC Voltage Rating
Not Rated
DC Voltage Rating
500V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 2-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series, with a 4 A amp rating and a C curve type. It is rated for 500V DC with a maximum AIR rating of 5kA at 250V DC, and features screw clamp terminals. This device is not rated for AC voltage.

Frequently Asked Questions

What is the SCHNEIDER C60H-DC supplementary protector used for?

The SCHNEIDER C60H-DC supplementary protector is used for DC circuit protection in industrial control panels, solar arrays, and battery systems. It is a 2-pole UL1077 device rated for 500V DC with a 4 A amp rating and C curve, providing overcurrent protection for DC-only circuits.

What are the specifications of the SCHNEIDER M9U21204 supplementary protector?

The SCHNEIDER M9U21204 is a 4 A, 500V DC supplementary protector with a C curve type and 5kA interrupting rating at 250V DC. It features screw clamp terminals, is not rated for AC, and mounts on a DIN rail. It is part of the C60H-DC series and complies with UL1077.

Where to buy SCHNEIDER C60H-DC supplementary protectors worldwide?

You can source SCHNEIDER C60H-DC supplementary protectors from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on the M9U21204 model.

How to install a SCHNEIDER C60H-DC supplementary protector on a DIN rail?

To install the SCHNEIDER C60H-DC supplementary protector, snap it onto a standard 35 mm DIN rail. Ensure the DC supply is off, connect wires to the screw clamp terminals per the wiring diagram, and torque to the specified value. The C curve provides magnetic trip for moderate inrush currents.
