SCHNEIDER Pilot Light Head: 22 mm Panel Mounting Hole Dia, Blue/Green/Orange/Red/White - Pilot-Light Heads
SCHNEIDERPilot-Light Heads

SCHNEIDER Pilot Light Head: 22 mm Panel Mounting Hole Dia, Blue/Green/Orange/Red/White

The SCHNEIDER ELECTRIC Pilot Light Head (MPN ZB4BV003) is a pilot-light head with a 22 mm panel mounting hole diameter, compatible with the XB4 series. It accepts a Universal LED Module and is available in Blue…

SKU 3G-OTH-30428

Brand
SCHNEIDER
Item
Pilot Light Head: 22 mm Panel Mounting Hole Dia, Blue/Green/Orange/Red/White
Category
Pilot-Light Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4BV003
Type
Blue/Green/Orange/Red/White, LED
Compatible with Series
XB4
Compatible Lamp Module Type
Universal LED Module
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Pilot Light Head (MPN ZB4BV003) is a pilot-light head with a 22 mm panel mounting hole diameter, compatible with the XB4 series. It accepts a Universal LED Module and is available in Blue, Green, Orange, Red, and White colors.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC ZB4BV003 pilot light head used for?

The SCHNEIDER ELECTRIC ZB4BV003 pilot light head provides visual status indication on industrial control panels. It is used in manufacturing, process control, and automation applications to signal machine status, alarms, or operational modes. It mounts in a 22 mm panel hole and accepts a Universal LED Module for illumination.

What are the specifications of the SCHNEIDER ZB4BV003 pilot light head?

The SCHNEIDER ZB4BV003 is a pilot-light head with a 22 mm panel mounting hole diameter. It is compatible with the XB4 series and accepts a Universal LED Module. Available colors include Blue, Green, Orange, Red, and White. The manufacturer part number is ZB4BV003.

Where to buy the SCHNEIDER ZB4BV003 pilot light head worldwide?

3G Electric supplies the SCHNEIDER ZB4BV003 pilot light head worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this genuine SCHNEIDER component to any country.

How to install the SCHNEIDER ZB4BV003 pilot light head?

Install the SCHNEIDER ZB4BV003 pilot light head by inserting it into a 22 mm panel cutout and securing it with the provided mounting nut. Ensure the Universal LED Module is correctly seated before tightening. Follow standard panel wiring practices and verify voltage compatibility with the LED module. Always consult the XB4 series installation guide.
