SUBURBAN Angle Plate: Cast Iron, 6 in L x 6 in W x 8 in H, 0.0005 in Square & Parallel - Universal Right-Angle Irons
SUBURBANUniversal Right-Angle Irons

SUBURBAN Angle Plate: Cast Iron, 6 in L x 6 in W x 8 in H, 0.0005 in Square & Parallel

The SUBURBAN Angle Plate is a universal right-angle iron made of cast iron, measuring 6 inches long by 6 inches wide by 8 inches high. It features a square and parallel tolerance of 0.0005 inches and a ground finish…

SKU 3G-OTH-207710

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 6 in L x 6 in W x 8 in H, 0.0005 in Square & Parallel
Category
Universal Right-Angle Irons
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SUBURBAN
Manufacturer Part Number
URA-060608-G
Type
Ground
H
6 in L x 6 in W x 8 in
Square & Parallel
0.0005 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SUBURBAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SUBURBAN Angle Plate is a universal right-angle iron made of cast iron, measuring 6 inches long by 6 inches wide by 8 inches high. It features a square and parallel tolerance of 0.0005 inches and a ground finish with a 0.00025-inch specification. This product is identified by manufacturer part number URA-060608-G.

Frequently Asked Questions

What is a SUBURBAN angle plate used for?

A SUBURBAN angle plate is used in precision machining and inspection to hold workpieces at a right angle. It is commonly employed in toolrooms, quality labs, and manufacturing for layout, setup, and measurement tasks requiring high squareness and parallelism.

What are the specifications of the SUBURBAN URA-060608-G angle plate?

The SUBURBAN URA-060608-G is a cast iron universal right-angle iron measuring 6 in L x 6 in W x 8 in H. It has a square and parallel tolerance of 0.0005 in and a ground finish with a 0.00025 in specification. The manufacturer part number is URA-060608-G.

Where to buy SUBURBAN angle plates worldwide?

You can source SUBURBAN angle plates worldwide through 3G Electric. As a global industrial equipment distributor, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on the URA-060608-G model.

How to maintain a SUBURBAN cast iron angle plate?

To maintain a SUBURBAN cast iron angle plate, keep it clean and lightly oiled to prevent rust. Store it on a flat surface away from moisture. Regularly check the ground surfaces for nicks or burrs and use a stone to dress them gently. Avoid dropping or overloading the plate.

Used in

Common applications for SUBURBAN
Surface grinding setup — SUBURBAN magnetic sine plates (e.g., MSP-126-S2) for angular workpiece positioning
Inspection and quality control — SUBURBAN steel straight edges (e.g., SE-12-TS) for checking flatness of machine tables
Toolroom fixturing — SUBURBAN slotted cast iron angle plates (e.g., SAW-120908) for holding workpieces during milling
Compound angle machining — SUBURBAN compound sine plates (e.g., SPC-1212-S2) for multi-axis angular setups
Precision grinding of small parts — SUBURBAN hardened steel angle plates (e.g., AP-334-S0) with 0.0002 in tolerance for tight-tolerance workholding
