ELVSolenoid Valves

ELV Stainless steel solenoid steam valve D 1"1/4

ELV stainless steel solenoid steam valve with DN 1¼ connection handles steam applications up to 10 bar operating pressure and 35 mm passage diameter. Cv value of 16 delivers reliable flow control in industrial steam…

SKU 3G-CBM-03272

Also listed as: ELV 40010 · ELV-40010

Brand

ELV

Item

Stainless steel solenoid steam valve D 1"1/4

Local availability & support — Singapore

Local office: 20 Woodlands Link #09-05, Singapore 738733
Phone: +65 8878 8355
Delivery: Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
Payment: Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
Ships to: Singapore

Technical Specifications

ELV

fluid

Steam

cv value

16

connection

1"

max pressure bar

10

connection diameter

1"1/4

passage diameter mm

35

operating pressure bar

0.5 - 10

max fluid viscosity cst

50

max differential pressure bar

25

Datasheet Content

Electrovannes inox NF vapeur                                                     Code

Electrovanne vapeur 3/8”                                                                           ELV40002


Electrovanne vapeur 1/2”                                                                           ELV40004


Electrovanne vapeur 3/4”                                                                           ELV40006


Electrovanne vapeur 1”                                                                             ELV40008


Electrovanne vapeur 1”1/4                                                                          3G-CBM-03272


Electrovanne vapeur 1”1/2                                                                          ELV40012



Caractéristiques techniques
            Modèle             ELV40002   ELV40004   ELV40006     ELV40008       3G-CBM-03272   ELV40012    ELV40014
Diamètre Raccord                3/8”       1/2”       3/4”           1”          1”1/4      1”1/2         2”
Diamètre passage               15mm       15mm       20mm          25mm          35mm       35mm         50mm
Pression différentielle max.     25         25         25            25            25         25          25
Valeur CV                        4.5        4.5        9.3          13.2           16         26          48
Dim. A mm                        75         75         85           100           120        120         150
Dim. C mm                       129        129        141           148           168        168         190
Viscosité fluide                                             Moins de 50 CST
Fluide                                                             Vapeur
Pression fonctionnement                                         0.5 ~ 10 bar
Pression maxi                                                      10 bar
Température maxi                                                5°C ~ 180°C
Tension                                                      +/- 10% - AC230V
Matériel corps                                                   Acier inox
Membrane                                                            Teflon
Mode opération                                                  Action directe
Type                                                        Normalement fermée


PIÈCES DE RECHANGES POUR VANNES
            Modèle             ELV40002   ELV40004   ELV40006     ELV40008       3G-CBM-03272   ELV40012    ELV40014
Référence bobine 220 V         ELV80515   ELV80515   ELV80515     ELV80515       ELV80515   ELV80515    ELV80515
Référence bobine 110 V            -          -          -             -             -          -           -
Référence bobine AC 48 V          -          -          -             -             -          -           -
Référence bobine AC 24 V          -          -          -             -             -          -           -
Référence bobine AC 12 V          -          -          -             -             -          -           -
Référence bobine DC 24 V       ELV81515   ELV81515   ELV81515     ELV81515       ELV81515   ELV81515    ELV81515
Référence bobine DC 12 V       ELV81530   ELV81530   ELV81530     ELV81530       ELV81530   ELV81530    ELV81530
Référence membrane NBR            -          -          -             -             -          -           -
Référence membrane EPDM           -          -          -             -             -          -           -
Référence membrane VITON          -          -          -             -             -          -           -


                                                                                                                   255

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the ELV stainless steel solenoid steam valve D 1"1/4 used for?

The ELV stainless steel solenoid steam valve D 1"1/4 is used for automated on-off flow control of steam in industrial systems. It handles steam up to 10 bar operating pressure and 180 °C, making it suitable for process heating, sterilization, and steam distribution in manufacturing and food processing plants.

What are the specifications of the ELV stainless steel solenoid steam valve D 1"1/4?

The ELV valve has a 1"1/4 connection, 35 mm passage diameter, Cv value of 16, and operates from 0.5 to 10 bar. Maximum differential pressure is 25 bar, fluid viscosity under 50 cSt, and temperature range 5 °C to 180 °C. The body is stainless steel with a Teflon membrane, and it is normally closed, direct-acting on AC 230 V.

Where to buy the ELV stainless steel solenoid steam valve D 1"1/4 in Singapore?

3G Electric supplies the ELV stainless steel solenoid steam valve D 1"1/4 to Singapore. We source and deliver this valve, handling logistics, customs clearance, and last-mile delivery to your facility. Contact us for pricing and lead time on this ELV steam valve.

How to install the ELV stainless steel solenoid steam valve D 1"1/4?

Install the ELV valve with the flow direction matching the arrow on the body, in a horizontal or vertical pipe. Ensure the steam line is clean and free of debris. Use appropriate thread sealant on the 1"1/4 connection. Wire the AC 230 V coil per local codes, and test for leaks before full operation.

Used in

Common applications for ELV

Pneumatic automation and directional control — ELV 2/2-way and 3/2-way pilot-operated solenoid valves in compressed-air circuits

Fluid-power machinery — ELV cavity cartridges and manifold-integrated solenoids in hydraulic and lubrication systems

Packaging and filling equipment — ELV proportional and on-off solenoid valves for rapid actuation and media switching

Water treatment and circulation systems — ELV valves rated for continuous water flow control and process isolation

Gas burner and combustion control — ELV solenoid coils for gas isolation and pilot fuel regulation in industrial burner systems

Maintenance and retrofit projects — ELV replacement solenoid coils and membrane kits for in-service valve replacement without removing the valve body
