EATON Lighted Rocker Switch: 2 Positions, SPST - General Purpose Rocker Switches
EATONGeneral Purpose Rocker Switches

EATON Lighted Rocker Switch: 2 Positions, SPST

The EATON NGR Series Lighted Rocker Switch (MPN NGR15061BNAAN) is a general-purpose rocker switch with a 2-position, SPST, Off/On configuration. It features an illuminated operator and is rated for AC contact at 10 A…

SKU 3G-OTH-34705

Brand
EATON
Item
Lighted Rocker Switch: 2 Positions, SPST
Category
General Purpose Rocker Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
NGR15061BNAAN
Series
NGR
Displayed Brand
EATON
AC Contact Rating
10 A @ 250 V
DC Contact Rating
15 A @ 28 V
Operator Illumination
Illuminated
Terminal Connection Type
0.25 in Quick Connect Tab
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NGR Series Lighted Rocker Switch (MPN NGR15061BNAAN) is a general-purpose rocker switch with a 2-position, SPST, Off/On configuration. It features an illuminated operator and is rated for AC contact at 10 A @ 250 V and DC contact at 15 A @ 28 V, with a 0.25 in Quick Connect Tab terminal connection.

Frequently Asked Questions

What is the EATON NGR15061BNAAN lighted rocker switch used for?

The EATON NGR15061BNAAN is a general-purpose SPST rocker switch used for on/off control in industrial panels, machinery, and equipment. Its illuminated operator provides clear status indication, making it suitable for applications requiring visual confirmation of power state.

What are the specifications of the EATON NGR15061BNAAN rocker switch?

The EATON NGR Series switch (MPN NGR15061BNAAN) is a 2-position SPST Off/On illuminated rocker switch. It has an AC contact rating of 10 A @ 250 V and a DC contact rating of 15 A @ 28 V, with a 0.25 in Quick Connect Tab terminal connection.

Where to buy the EATON NGR15061BNAAN rocker switch worldwide?

3G Electric supplies the EATON NGR15061BNAAN rocker switch to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the EATON NGR15061BNAAN lighted rocker switch?

Install the EATON NGR15061BNAAN by connecting the 0.25 in Quick Connect Tab terminals to the circuit. Ensure power is off before wiring. The SPST Off/On configuration controls a single circuit. Follow standard electrical safety practices and verify ratings match your application.
