EATON Manual Motor Protector: Non-Reversing, 3 Poles, 4 A, Electronic Protection - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Manual Motor Protector: Non-Reversing, 3 Poles, 4 A, Electronic Protection

The EATON Manual Motor Protector: Non-Reversing (MPN XTPE004BCS) is a non-reversing starter with an electronic overload, featuring 3 poles and a 4 A rating. It operates with a selector switch and has a maximum…

SKU 3G-OTH-41094

Brand
EATON
Item
Manual Motor Protector: Non-Reversing, 3 Poles, 4 A, Electronic Protection
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
XTPE004BCS
Type
4 A, Electronic Protection, Selector Switch
Poles
3
Frame Size (Width)
45mm (B Frame)
Maximum Voltage Rating
600V AC
Thermal Units Required
None (Not Applicable to Electronic Overloads)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Manual Motor Protector: Non-Reversing (MPN XTPE004BCS) is a non-reversing starter with an electronic overload, featuring 3 poles and a 4 A rating. It operates with a selector switch and has a maximum voltage rating of 600V AC, housed in a 45mm (B Frame) width. No thermal units are required as the electronic overload eliminates the need for them.

Frequently Asked Questions

What is the EATON XTPE004BCS manual motor protector used for?

The EATON XTPE004BCS is a non-reversing manual motor protector with electronic overload protection, rated 4 A and 600V AC. It is used to protect motors in industrial applications such as conveyors, pumps, and fans, providing reliable overload and short-circuit protection without requiring thermal units.

What are the specifications of the EATON XTPE004BCS?

The EATON XTPE004BCS is a 3-pole, non-reversing manual motor protector with electronic protection, rated 4 A and 600V AC. It features a selector switch, a 45mm B Frame width, and requires no thermal units. The electronic overload eliminates the need for heater elements.

Where to buy the EATON XTPE004BCS worldwide?

3G Electric supplies the EATON XTPE004BCS manual motor protector to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this Eaton part.

How to select the correct EATON manual motor protector for a motor?

To select the correct EATON manual motor protector, match the full-load current of your motor to the protector's ampere rating, such as the 4 A rating of the XTPE004BCS. Ensure voltage rating (600V AC) and pole count (3) meet your system. Electronic overload types like this one eliminate thermal unit selection.
