EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 2, 45 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 2, 45 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 2 unit features a 45 A rating and a 440/480V AC coil voltage, with a…

SKU 3G-OTH-42976

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 2, 45 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19GN0C5E020
Type
NEMA Size 2, 45 A
Phase
Three
Poles
3
AC Coil
480V
Operator
None
Coil Voltage
440/480V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 2 unit features a 45 A rating and a 440/480V AC coil voltage, with a 1NO auxiliary contact and a pilot light for signaling. It requires no thermal units, as the electronic overload eliminates the need for them.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications such as pumps, fans, and conveyors. Its electronic overload protects the motor from damage without requiring thermal units, making it suitable for continuous-duty operations.

What are the specifications of the EATON AN19GN0C5E020 motor starter?

The EATON AN19GN0C5E020 is a NEMA Size 2, non-reversing starter rated 45 A with a 440/480V AC coil voltage. It includes one normally open auxiliary contact and a pilot light for signaling. The electronic overload eliminates the need for thermal units, simplifying setup.

Where to buy the EATON AN19GN0C5E020 motor starter worldwide?

You can source the EATON AN19GN0C5E020 motor starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the product reaches your facility reliably.

How to install the EATON NEMA Size 2 motor starter?

Mount the starter on a flat surface, connect three-phase power to the line terminals, and wire the motor to the load terminals. Set the electronic overload dial to the motor's full-load current. Ensure the 440/480V AC coil voltage matches your control circuit before energizing.
