GRACO Electric Diaphragm Pump: Stainless Steel Body, Single Phase, 100-120V AC - USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
GRACOUSP Class VI-Compliant Pharmaceutical-Grade EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Single Phase, 100-120V AC

The GRACO Electric Diaphragm Pump (MPN HE30-0504) is a USP Class VI-compliant pharmaceutical-grade EODD pump with a stainless steel body. It operates on single-phase 100-120V AC power and features a 1-inch…

SKU 3G-OTH-86001

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Single Phase, 100-120V AC
Category
USP Class VI-Compliant Pharmaceutical-Grade EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE30-0504
Type
Single Phase, 1 in, PTFE Valve
AC
100-120V
Seat Material
316 SS
Nameplate Voltage
100-120V AC
Surface Roughness
20 Ra
Diaphragm Material
PTFE with EPDM Backing
Check Valve Material
PTFE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump (MPN HE30-0504) is a USP Class VI-compliant pharmaceutical-grade EODD pump with a stainless steel body. It operates on single-phase 100-120V AC power and features a 1-inch connection, PTFE check valves, and a PTFE diaphragm with EPDM backing. The pump includes 316 SS seat material and a surface roughness of 20 Ra.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE30-0504 used for?

The GRACO HE30-0504 is a USP Class VI-compliant pharmaceutical-grade EODD pump designed for sanitary transfer of sensitive fluids in biopharma, food, and cosmetic industries. Its stainless steel body and 20 Ra surface finish meet clean-in-place requirements, while PTFE wetted parts resist aggressive chemicals.

What are the specifications of the GRACO HE30-0504 pump?

The GRACO HE30-0504 is a single-phase electric diaphragm pump with a 1-inch connection, 100-120V AC input, 316 SS seats, PTFE check valves, and a PTFE diaphragm with EPDM backing. It delivers a surface roughness of 20 Ra and is USP Class VI compliant for pharmaceutical-grade applications.

Where to buy the GRACO HE30-0504 pump worldwide?

3G Electric supplies the GRACO HE30-0504 pump worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact our team for a quote and lead time on this USP Class VI-compliant pharmaceutical-grade EODD pump.
