IEC Miniature Cct Breaker, 30 A - C-Curve, 4-Pole UL489 DIN Rail-Mount Miniature Circuit Breakers
IECC-Curve, 4-Pole UL489 DIN Rail-Mount Miniature Circuit Breakers

IEC Miniature Cct Breaker, 30 A

The IEC Miniature Cct Breaker, 30 A, 3 in (MPN FAZ-C30/4-NA) is a C-Curve, 4-Pole UL489 DIN Rail-Mount Miniature Circuit Breaker from the brand IEC. It is rated for 480V AC with an interrupting capacity of 10 kA at…

SKU 3G-OTH-129717

Brand
IEC
Item
Miniature Cct Breaker, 30 A
Category
C-Curve, 4-Pole UL489 DIN Rail-Mount Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

IEC
Manufacturer Part Number
FAZ-C30/4-NA
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

IEC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The IEC Miniature Cct Breaker, 30 A, 3 in (MPN FAZ-C30/4-NA) is a C-Curve, 4-Pole UL489 DIN Rail-Mount Miniature Circuit Breaker from the brand IEC. It is rated for 480V AC with an interrupting capacity of 10 kA at 277/480V AC and features screw-type terminals. This product is manufactured by EATON.

Frequently Asked Questions

What is the IEC FAZ-C30/4-NA miniature circuit breaker used for?

The IEC FAZ-C30/4-NA is a C-Curve, 4-pole UL489 miniature circuit breaker rated 30 A at 480V AC. It is used for overcurrent protection in industrial control panels, distribution boards, and equipment branch circuits where a 3-inch-wide, DIN-rail-mounted breaker with screw terminals is required.

What are the specifications of the IEC FAZ-C30/4-NA circuit breaker?

The IEC FAZ-C30/4-NA is a 30 A, 4-pole, C-Curve miniature circuit breaker rated 480V AC with an interrupting capacity of 10 kA at 277/480V AC. It features screw-type terminals and is UL489 listed for DIN-rail mounting. This model is manufactured by EATON.

Where to buy the IEC FAZ-C30/4-NA circuit breaker worldwide?

You can source the IEC FAZ-C30/4-NA miniature circuit breaker from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this EATON-manufactured breaker.

How to install the IEC FAZ-C30/4-NA miniature circuit breaker?

Install the IEC FAZ-C30/4-NA by snapping it onto a standard 35 mm DIN rail. Ensure the breaker is off before connecting conductors to the screw terminals. Torque terminals to the manufacturer's specification (typically 2.8 Nm). Verify line and load connections match the 480V AC rating and 10 kA interrupting capacity.

Used in

Common applications for IEC
Industrial panelboards — IEC FAZ-C series 4-pole miniature circuit breakers for branch circuit protection in 480 V AC distribution
Motor control centers — IEC FAZ-C series MCBs for overcurrent protection of motor circuits in C-curve applications
Heating equipment — IEC GFP series ground fault protectors (e.g., 25 A, 260 mA) for personnel protection in electric heaters
Pump systems — IEC GFP series (e.g., 63 A, 26 mA) for ground fault protection in industrial pump controls
Commercial building electrical rooms — IEC FAZ-C series breakers for lighting and receptacle circuits in 277/480 V AC systems
Machine tool disconnects — IEC FAZ-C series MCBs as supplementary protection in control panels for manufacturing equipment
