SCHNEIDER Lamp Module and Contact Block: 22 mm Panel Mounting Size, 1NO/1NC, White - Contact & Light Block Assemblies
SCHNEIDERContact & Light Block Assemblies

SCHNEIDER Lamp Module and Contact Block: 22 mm Panel Mounting Size, 1NO/1NC, White

The SCHNEIDER ELECTRIC Lamp Module and Contact Block is a 22 mm panel-mounting contact and light block assembly from the XB4 series. It features a 1NO/1NC contact configuration, includes a white LED bulb, and…

SKU 3G-OTH-30715

Brand
SCHNEIDER
Item
Lamp Module and Contact Block: 22 mm Panel Mounting Size, 1NO/1NC, White
Category
Contact & Light Block Assemblies
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4BW0B15
Type
1NO/1NC, White, LED
Includes Bulb
Bulb Included
Lamp Module Voltage
24V AC/DC
Compatible with Series
XB4
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Lamp Module and Contact Block is a 22 mm panel-mounting contact and light block assembly from the XB4 series. It features a 1NO/1NC contact configuration, includes a white LED bulb, and operates on 24V AC/DC power.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC ZB4BW0B15 lamp module and contact block used for?

The SCHNEIDER ELECTRIC ZB4BW0B15 is a 22 mm panel-mounting contact and light block assembly from the XB4 series. It provides a 1NO/1NC contact configuration with a white LED indicator, commonly used in industrial control panels for status indication and switching.

What are the specifications of the SCHNEIDER ZB4BW0B15?

The SCHNEIDER ZB4BW0B15 is a 22 mm panel-mounting lamp module and contact block. It features a 1NO/1NC contact configuration, includes a white LED bulb, and operates on 24V AC/DC power. It is compatible with the XB4 series and has manufacturer part number ZB4BW0B15.

Where to buy the SCHNEIDER ZB4BW0B15 worldwide?

3G Electric supplies the SCHNEIDER ZB4BW0B15 lamp module and contact block to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this XB4 series component.

How to install the SCHNEIDER XB4 lamp module and contact block?

Install the SCHNEIDER ZB4BW0B15 by mounting it in a 22 mm panel cutout. Connect the 1NO/1NC contacts per your control circuit wiring, and supply 24V AC/DC to the integrated white LED. Always follow standard industrial electrical safety practices and consult the manufacturer's documentation for torque and wiring details.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.
