SCHNEIDER Lamp Module and Contact Block: 22 mm Panel Mounting Size, 2NO, White - Contact & Light Block Assemblies
SCHNEIDERContact & Light Block Assemblies

SCHNEIDER Lamp Module and Contact Block: 22 mm Panel Mounting Size, 2NO, White

The SCHNEIDER ELECTRIC Lamp Module and Contact Block is a 22 mm panel-mounting contact and light block assembly from the XB4 series. It includes a white LED bulb and features a 2NO contact configuration, with a lamp…

SKU 3G-OTH-30683

Brand
SCHNEIDER
Item
Lamp Module and Contact Block: 22 mm Panel Mounting Size, 2NO, White
Category
Contact & Light Block Assemblies
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4BW0G13
Type
2NO, White, LED
Includes Bulb
Bulb Included
Lamp Module Voltage
110 to 120V AC
Compatible with Series
XB4
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Lamp Module and Contact Block is a 22 mm panel-mounting contact and light block assembly from the XB4 series. It includes a white LED bulb and features a 2NO contact configuration, with a lamp module voltage of 110 to 120V AC (MPN ZB4BW0G13).

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC ZB4BW0G13 lamp module and contact block used for?

This 22 mm panel-mounting assembly provides a white LED indicator with a 2NO contact block for industrial control stations. It is commonly used in machinery, conveyors, and process equipment to signal status and enable switching, compatible with the XB4 series.

What are the specifications of the SCHNEIDER ZB4BW0G13?

The ZB4BW0G13 is a 22 mm panel-mounting contact and light block assembly from the XB4 series. It includes a white LED bulb, 2NO contact configuration, and operates at 110 to 120V AC. The bulb is included, and it is manufactured by SCHNEIDER.

Where to buy the SCHNEIDER ZB4BW0G13 worldwide?

3G Electric supplies the SCHNEIDER ZB4BW0G13 lamp module and contact block to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this XB4 series component.

How to install the SCHNEIDER ZB4BW0G13 contact block?

Mount the assembly into a 22 mm panel cutout, secure with the supplied nut, and wire the 2NO contacts according to your control circuit. Ensure the supply voltage matches the 110 to 120V AC rating. Refer to the XB4 series manual for detailed wiring and torque specifications.
