SUBURBAN Angle Plate: Cast Iron, 6 in L x 8 in W x 10 in H, 0.0005 in Square & Parallel - Plain Cast Iron Angle Plates
SUBURBANPlain Cast Iron Angle Plates

SUBURBAN Angle Plate: Cast Iron, 6 in L x 8 in W x 10 in H, 0.0005 in Square & Parallel

The SUBURBAN Angle Plate: Cast Iron is a plain cast iron angle plate designed for precision layout and inspection work. It measures 6 in L x 8 in W x 10 in H, with a flatness of 0.0005 in and parallelism of 0.002 in…

SKU 3G-OTH-182514

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 6 in L x 8 in W x 10 in H, 0.0005 in Square & Parallel
Category
Plain Cast Iron Angle Plates
Available to Order
