EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase operation. This NEMA Size 5 unit is rated for 270 A and features a 208V AC coil, a 1NO auxiliary…

SKU 3G-OTH-43647

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19SN0E5G300
Type
NEMA Size 5, 270 A
Phase
Three
Poles
3
AC Coil
208V
Operator
None
Coil Voltage
208V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase operation. This NEMA Size 5 unit is rated for 270 A and features a 208V AC coil, a 1NO auxiliary contact, and a pilot light for signaling. It requires no thermal units, as electronic overloads are integrated.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications such as pumps, conveyors, and compressors. Its NEMA Size 5, 270 A rating suits heavy-duty motor control, while the integrated electronic overloads protect motors from damage without requiring thermal units.

What are the specifications of the EATON NEMA Magnetic Motor Starter?

This EATON starter is a non-reversing, three-pole NEMA Size 5 unit rated for 270 A. It has a 208V AC coil, one normally open auxiliary contact, and a pilot light for signaling. Electronic overloads are integrated, so no thermal units are needed. The manufacturer part number is AN19SN0E5G300.

Where to buy the EATON NEMA Magnetic Motor Starter worldwide?

You can source the EATON NEMA Magnetic Motor Starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON components for your motor control needs.

How to select the correct EATON NEMA Magnetic Motor Starter?

Select the starter based on motor full-load current, voltage, and duty cycle. For this EATON NEMA Size 5 unit, ensure your motor draws up to 270 A and uses a 208V AC control circuit. Verify the three-phase supply and that the integrated electronic overloads match your motor's thermal protection requirements.
