EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase operation. This NEMA Size 5 unit features a 270 A rating and a 440/480V AC coil voltage, with a 1NO…

SKU 3G-OTH-43832

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19SN0C5G300
Type
NEMA Size 5, 270 A
Phase
Three
Poles
3
AC Coil
480V
Operator
None
Coil Voltage
440/480V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase operation. This NEMA Size 5 unit features a 270 A rating and a 440/480V AC coil voltage, with a 1NO auxiliary contact form and an included pilot light for signaling. It requires no thermal units, as they are not applicable to electronic overloads.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used to start and protect three-phase motors in industrial applications. It provides overload protection via electronic overloads and includes a pilot light for status signaling. Common in manufacturing, HVAC, and pumping systems, it ensures reliable motor control under heavy loads.

What are the specifications of the EATON AN19SN0C5G300 motor starter?

This EATON starter is a NEMA Size 5, non-reversing unit rated at 270 A with three poles. It operates on a 440/480V AC coil voltage and includes one normally open auxiliary contact. The electronic overload eliminates the need for thermal units, and a built-in pilot light provides visual signaling.

Where to buy the EATON AN19SN0C5G300 motor starter worldwide?

You can source the EATON AN19SN0C5G300 motor starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON components for industrial motor control.

How to select the correct EATON NEMA motor starter for a motor?

Select the starter based on motor full-load current, voltage, and duty cycle. For this EATON Size 5 unit, ensure the motor's FLA does not exceed 270 A and the coil voltage matches your control circuit (440/480V AC). Verify enclosure type and auxiliary contact needs; electronic overloads simplify setup by eliminating thermal unit selection.
