EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 00, 9 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 00, 9 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, featuring three poles, NEMA Size 00, and a 9 A rating. It operates with a 24V AC coil voltage and includes a pilot light and…

SKU 3G-OTH-41060

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 00, 9 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19AN0T5E020
Type
NEMA Size 00, 9 A
Phase
Three
Poles
3
AC Coil
24V
Operator
None
Coil Voltage
24V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, featuring three poles, NEMA Size 00, and a 9 A rating. It operates with a 24V AC coil voltage and includes a pilot light and one normally open auxiliary contact. This three-phase starter requires no thermal units, as it is designed for electronic overload protection.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter AN19AN0T5E020 used for?

This EATON non-reversing magnetic motor starter controls three-phase motors up to 9 A, providing electronic overload protection. It is commonly used in industrial machinery, conveyors, pumps, and HVAC equipment where reliable starting and overload protection are required.

What are the specifications of the EATON AN19AN0T5E020 starter?

The EATON AN19AN0T5E020 is a NEMA Size 00, 3-pole, non-reversing starter rated 9 A at 24V AC coil voltage. It includes one normally open auxiliary contact and a pilot light. Electronic overload protection eliminates the need for thermal units.

Where to buy the EATON AN19AN0T5E020 motor starter worldwide?

3G Electric supplies the EATON AN19AN0T5E020 motor starter to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time.

How to select the correct EATON NEMA magnetic motor starter for a motor?

Match the starter's NEMA size and ampere rating to the motor's full-load current and voltage. For the EATON AN19AN0T5E020, ensure the motor is three-phase, 9 A or less, and the control circuit uses 24V AC. Electronic overloads simplify setup by eliminating thermal unit selection.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Products

3G Electric supplies EATON non-reversing starters with electronic overloads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
