IFM Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC, 4-Pin M12 Connector - Pressure Transmitters with 4-Pin M12 Connector
IFMPressure Transmitters with 4-Pin M12 Connector

IFM Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC, 4-Pin M12 Connector

The IFM PX3224 is a pressure transmitter from the PX series, featuring a 0 psi to 100 psi range with a 4 to 20mA DC output and a 4-Pin M12 Connector. It has a 1/4 in Male NPT process connection, a stainless steel…

SKU 3G-OTH-176683

Brand
IFM
Item
Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC, 4-Pin M12 Connector
Category
Pressure Transmitters with 4-Pin M12 Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

IFM
Manufacturer Part Number
PX3224
Series
PX
Type
IP65
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.75%
Male NPT
1/4 in
IP Rating
IP65
Overpressure
1,087 psi
M12 Connector
4-Pin
Burst Pressure
2,175 psi
Housing Material
Stainless Steel
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

IFM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The IFM PX3224 is a pressure transmitter from the PX series, featuring a 0 psi to 100 psi range with a 4 to 20mA DC output and a 4-Pin M12 Connector. It has a 1/4 in Male NPT process connection, a stainless steel housing, and an IP65 rating. Accuracy is ±0.75%, with an overpressure limit of 1,087 psi and a burst pressure of 2,175 psi. No NIST-traceable calibration certificate is included.

Frequently Asked Questions

What is the IFM PX3224 pressure transmitter used for?

The IFM PX3224 pressure transmitter measures pressure from 0 psi to 100 psi in industrial hydraulic and pneumatic systems. It outputs a 4 to 20mA DC signal via a 4-Pin M12 Connector, making it suitable for monitoring and control applications in manufacturing, process automation, and fluid power systems.

What are the specifications of the IFM PX3224 pressure transmitter?

The IFM PX3224 has a 0 psi to 100 psi range, ±0.75% accuracy, 4 to 20mA DC output, and a 4-Pin M12 Connector. It features a 1/4 in Male NPT process connection, stainless steel housing, IP65 rating, overpressure limit of 1,087 psi, and burst pressure of 2,175 psi. No NIST-traceable calibration certificate is included.

Where to buy the IFM PX3224 pressure transmitter worldwide?

You can source the IFM PX3224 pressure transmitter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive pricing and reliable sourcing for this IFM model.

How to install the IFM PX3224 pressure transmitter?

Install the IFM PX3224 by connecting the 1/4 in Male NPT to a compatible process port using thread sealant. Wire the 4-Pin M12 Connector per the pinout for 4 to 20mA DC output. Ensure the IP65 rating is maintained by tightening the connector properly. Avoid exceeding 1,087 psi overpressure to prevent damage.

Used in

Common applications for IFM
Automotive assembly — IFM inductive proximity sensors (e.g., IFS243) for detecting metal parts on conveyor lines
Packaging machinery — IFM photoelectric sensors (e.g., OGE282) for object presence detection in high-speed wrapping systems
Hydraulic systems — IFM pressure transmitters (e.g., PX3227) for monitoring fluid pressure in industrial presses
Material handling — IFM RFID tags (e.g., E80347) for tracking pallets and containers in warehouse logistics
Machine safety — IFM light curtains (e.g., OY009S) for finger protection on automated assembly stations
Field wiring — IFM M12 connectors (e.g., E18163) for quick sensor replacement in food processing equipment

IFM Products

3G Electric supplies IFM pressure transmitters with 4-pin m12 connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
